John Deere 510
Series: John Deere Loader Backhoe
The John Deere Loader Backhoe series from John Deere includes the 510. The engine delivers 59.7 kW, has 4 cylinders, with a displacement of 4,424.5 cm³. Rated speed is 2,500 rpm. The tank holds 128.7 litres. The gearbox has 8 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,300 rpm. The pump delivers 124.9 l/min. The hydraulic tank holds 113.2 litres. Working pressure is 137.9 bar. The cooling system holds 18.2 litres. The engine fitted is the 300 Series. The John Deere Loader Backhoe series covers 57 models. Rated output within it ranges from 30.6 to 97 kW; the 510 sits in the middle of that range with 59.7 kW. Its immediate neighbours are the 410D below it with 55.9 kW and the 315SG above it with 64.1 kW. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 15 verified figures from 1 source are on file.
Technical data
Engine
| Engine model | 300 Seriescorrect |
|---|---|
| Power | 59.7 kWcorrect |
| Rated speed | 2,500 rpmcorrect |
| Speed at max. torque | 1,300 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,424.5 cm³correct |
| Aspiration | naturally aspiratedcorrect |
| Coolant capacity | 18.2 lcorrect |
Drivetrain and chassis
| Gearbox type | powershift transmissioncorrect |
|---|---|
| Forward gears | 8correct |
| Reverse gears | 4correct |
Working data
| Pump flow | 124.9 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 113.2 lcorrect |
| Hydraulic pressure | 137.9correct |
| Fuel tank capacity | 128.7 lcorrect |
Frequently asked questions
How much power does the John Deere 510 have?
The John Deere 510 delivers 59.7 kW.
What engine does the John Deere 510 have?
4 cylinders, 4,424 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
