John Deere 410B

Series: John Deere Loader Backhoe

Source: https://www.pinterest.com/pin/john-deere-tractor-plowing-fie

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The John Deere 410B is a model in the John Deere Loader Backhoe series. The engine delivers 66.9 hp (46.2 kW), has 4 cylinders, with a displacement of 3,588.8 cm³. Rated speed is 2,500 rpm. The wheelbase measures 2,100.1 mm. Ground clearance is 307.8 mm. The tank holds 87.1 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,300 rpm. The pump delivers 113.6 l/min. The hydraulic tank holds 71.9 litres. Working pressure is 172.4 bar. The cooling system holds 16.3 litres. The electrical system runs on 12 V. The engine fitted is the 4-219D. The John Deere Loader Backhoe series covers 57 models. Rated output within it ranges from 43.6 to 121.7 hp; the 410B sits in the lower part of that range with 66.9 hp. Its immediate neighbours are the 310B below it with 65.9 hp and the 315C above it with 72 hp. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine model4-219Dcorrect
Power66.9 hp (46.2 kW)correct
Rated speed2,500 rpmcorrect
Speed at max. torque1,300 rpmcorrect
Cylinders4correct
Displacement3,588.8 cm³correct
Aspirationnaturally aspiratedcorrect
Coolant capacity16.3 lcorrect

Dimensions and weights

Wheelbase2,100.1correct
Ground clearance307.8correct

Drivetrain and chassis

Gearbox typemanual gearbox shift with first and second speeds having sliding collar engagement and tcorrect
Forward gears4correct
Reverse gears4correct
System voltage12 Vcorrect

Working data

Pump flow113.6 l/mincorrect
Hydraulic oil capacity71.9 lcorrect
Hydraulic pressure172.4correct
Fuel tank capacity87.1 lcorrect

Frequently asked questions

How much power does the John Deere 410B have?

The John Deere 410B delivers 66.9 hp.

What engine does the John Deere 410B have?

4 cylinders, 3,589 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
