John Deere 3375

Series: John Deere Skid Steer Loader

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The John Deere Skid Steer Loader series from John Deere includes the 3375. The engine delivers 19.3 hp (12.7 kW), has 3 cylinders, with a displacement of 685 cm³. Rated speed is 3,400 rpm. The wheelbase measures 810.8 mm. Ground clearance is 140.2 mm. The tank holds 22.7 litres. The pump delivers 30.3 l/min. Working pressure is 110.3 bar. The electrical system runs on 12 V. The engine fitted is the Series 220. The John Deere Skid Steer Loader series covers 29 models. Rated output within it ranges from 19.3 to 92.3 hp; the 3375 sits at the bottom of that range with 19.3 hp. Its immediate neighbours are the 4475 above it with 32.4 hp. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 13 verified figures from 1 source are on file.

Technical data

Engine

Engine modelSeries 220correct
Power19.3 hp (12.7 kW)correct
Rated speed3,400 rpmcorrect
Cylinders3correct
Displacement685 cm³correct

Dimensions and weights

Wheelbase810.8correct
Ground clearance140.2correct

Drivetrain and chassis

System voltage12 Vcorrect

Working data

Pump flow30.3 l/mincorrect
Hydraulic pressure110.3correct
Fuel tank capacity22.7 lcorrect

Other data

Height1,752.6correct

Frequently asked questions

How much power does the John Deere 3375 have?

The John Deere 3375 delivers 19.3 hp.

What engine does the John Deere 3375 have?

3 cylinders, 685 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
