John Deere 310E

Series: John Deere Loader Backhoe

Source: https://www.pinterest.com/pin/john-deere-tractor-plowing-fie

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 310E, John Deere offers a model from the John Deere Loader Backhoe series. The engine delivers 77.1 hp (52.9 kW), has 4 cylinders, with a displacement of 4,522.8 cm³. Rated speed is 2,200 rpm. The wheelbase measures 2,100.1 mm. Ground clearance is 307.8 mm. The tank holds 136.3 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. The pump delivers 106 l/min. The hydraulic tank holds 90.8 litres. Working pressure is 189.6 bar. The cooling system holds 16.3 litres. The electrical system runs on 12 V. The engine fitted is the 4045D. The John Deere Loader Backhoe series covers 57 models. Rated output within it ranges from 43.6 to 121.7 hp; the 310E sits in the middle of that range with 77.1 hp. Its immediate neighbours are the 310C below it with 76 hp and the 310G above it with 79.1 hp. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine model4045Dcorrect
Power77.1 hp (52.9 kW)correct
Rated speed2,200 rpmcorrect
Cylinders4correct
Displacement4,522.8 cm³correct
Aspirationnaturally aspiratedcorrect
Coolant capacity16.3 lcorrect

Dimensions and weights

Wheelbase2,100.1correct
Ground clearance307.8correct

Drivetrain and chassis

Gearbox type4-speed, helical cut gear, collar shift transmission synchromesh gearbox in all gears witcorrect
Forward gears4correct
Reverse gears4correct
System voltage12 Vcorrect

Working data

Pump flow106 l/mincorrect
Hydraulic oil capacity90.8 lcorrect
Hydraulic pressure189.6correct
Fuel tank capacity136.3 lcorrect

Frequently asked questions

How much power does the John Deere 310E have?

The John Deere 310E delivers 77.1 hp.

What engine does the John Deere 310E have?

4 cylinders, 4,523 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
