John Deere 180CW
Series: John Deere Mobile Excavator
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
John Deere wheeled excavators 75C to 220DW – fitted with Isuzu engines: C and D as generations, W for the wheeled drive, Isuzu four- to six-cylinders, 40 to 119 kW, operating weights above 22 t
John Deere's wheeled excavators represent the group's European and Asian construction-equipment arm, whose wheeled machines, unlike the North American crawler excavators, are not fitted with Deere's own engines but with Isuzu diesels: the smaller models with the four-cylinder CC-4JG1, the mid-range with the 4HK1X and 4BG1XABFA, the largest model with the six-cylinder 6BG1T. The type logic orders size roughly in ascending order through the number – from the small 75C to the large 220DW – the letters C and D mark successive series generations, and W stands for the wheeled version as against the crawler one. The wheeled excavator drives on the road between sites instead of needing to be transported, and works with outrigger pads in inner-city civil engineering.
Read on 3 more paragraphs
The register lists 5 versions with engines of 3,064 to 6,489 cm³, 4 to 6 cylinders, outputs of 40.3 to 118.6 kW and operating weights of 18,800 to 22,629 kg at 2,000 to 2,200 rpm.
Wheeled excavators fill the niche between compact excavators and heavy crawler excavators in sewer, utility and road construction, where road travel saves time and the outriggers provide the same stability as tracks.
On used machines, operating hours, the condition of the oscillating axle and tyres, leak-free hydraulic cylinders and swivel joint, play in boom and stick bearings, and parts supply count, which for the Isuzu engines runs through independent workshops and for excavator parts through Deere.
Sources: Kennwerte der Modelle John Deere Mobilbagger, John Deere (Hersteller)
Technical data
Engine
| Engine model | 4BG1XABFAcorrect |
|---|---|
| Power | 90.2 kWcorrect |
| Rated speed | 2,200 rpmcorrect |
| Speed at max. torque | 1,800 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,326.2 cm³correct |
| Aspiration | turbochargedcorrect |
| Coolant capacity | 19.3 lcorrect |
| Engine oil capacity | 15.9 lcorrect |
Dimensions and weights
| Wheelbase | 2,651.8correct |
|---|---|
| Ground clearance | 362.7correct |
| Unladen weight | 18,800 kgcorrect |
Drivetrain and chassis
| Gearbox type | hydrostatic transmissioncorrect |
|---|---|
| Forward gears | 2correct |
| Reverse gears | 2correct |
Working data
| Pump flow | 393.7 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 270.3 lcorrect |
| Hydraulic pressure | 343.4 barcorrect |
| Fuel tank capacity | 280.1 lcorrect |
Other data
| Cab height | 3,081.5correct |
|---|
Where this model stands
Power-to-weight ratio: 4.8 kW/t (90 kW / 18.8 t)
Stronger than 36% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the John Deere 180CW have?
The John Deere 180CW delivers 90.2 kW.
How much does the John Deere 180CW weigh?
The unladen weight is 18,800 kg.
What engine does the John Deere 180CW have?
4 cylinders, 4,326 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 20 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
