Iveco 40C/35N
Built: 2022-2023 · Series: 40C
More machines from model year 2022
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Iveco 40C – the weight class of the Daily chassis with reinforced rear axle, four-cylinder diesels of 2,286 to 2,998 cm³, Euro 3 to Euro V EEV, widths of 2,000 to 2,430 mm
Within the Iveco Daily range, the 40C is the weight class above the 35C: the first two digits of the type designation give the tonne class, here around 4 tonnes, and the following C denotes the rear axle laid out for twin rear wheels, a sturdier design that suits the 40C to box bodies, tippers and other heavier bodywork. The model suffixes show the emission stage of each model year, from Euro 3 through Euro 4 to the combination Euro V with EEV, the voluntarily stricter Enhanced Environmentally friendly Vehicle classification; T and DT mark turbodiesel variants, the number after the slash the engine output in hp. Newer chassis are additionally available with the automated Hi-Matic transmission, identifiable by the Himatic designation on the more recent model names.
Read on 3 more paragraphs
The register lists here 16 versions with four-cylinder diesel engines of 2,286 to 2,998 cm³, unladen weights from 1,910 to 3,240 kg, a gross weight of 3,500 kg and widths from 2,000 to 2,430 mm.
The 40C is the choice for trades, furniture transport and municipal services needing more payload or a sturdier rear axle than the 35C while staying below the 5-tonne class of the 50C; it competes directly with the Mercedes-Benz Sprinter, Ford Transit and MAN TGE in comparable body variants.
On used examples, rust on the chassis frame and spring mounts, the condition of the turbocharger and injection system, the clutch on manuals and the mechatronics on Hi-Matic gearboxes, the exhaust aftertreatment depending on the Euro stage, and mileage and the service book count; parts run through Iveco's dense service network.
Sources: Kennwerte der Modelle Iveco 40C, Iveco (Hersteller)
Technical data
Engine
| Cylinders | 4correct |
|---|---|
| Displacement | 2,998 cm³correct |
Dimensions and weights
| Length | 6,880 mmcorrect |
|---|---|
| Width | 2,320 mmcorrect |
| Wheelbase | 4,100 mmcorrect |
| Unladen weight | 3,208 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 160 km/hcorrect |
Frequently asked questions
How much does the Iveco 40C/35N weigh?
The unladen weight is 3,208 kg.
What is the gross vehicle weight of the Iveco 40C/35N?
3,500 kg.
What engine does the Iveco 40C/35N have?
4 cylinders, 2,998 cm³ displacement.
What are the dimensions of the Iveco 40C/35N?
6,880 mm × 2,320 mm.
When was the Iveco 40C/35N built?
Production years: 2022-2023.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 11 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
