ITM 285 2WD
Series: Other models
The ITM 285 is a tractor made by ITM. Under the bonnet works a four-cylinder engine displacing 4.1 litres, producing 76 hp (55.9 kW). With a rated speed of 2,000 rpm, it is built for pulling power, not for revving.
Width is 2.06 m. Empty, it weighs 2,812 kg.
Within the range, rated power spans from 47.7 to 113 hp; with 76 hp, the 285 sits in the lower third. Directly alongside are the 240 with 47.7 hp below and the 399 with 112 hp above.
Technical data
Engine
| Engine model | A4-248correct |
|---|---|
| Power | 76 hp (55.9 kW)correct |
| Rated speed | 2,000 rpmcorrect |
| Torque | 278.1correct |
| Speed at max. torque | 1,300 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,060.7 cm³correct |
| Coolant capacity | 14.4 lcorrect |
| Engine oil capacity | 8.3 lcorrect |
Dimensions and weights
| Width | 2,060.4correct |
|---|---|
| Wheelbase | 2,292.1correct |
| Unladen weight | 2,812 kgcorrect |
Drivetrain and chassis
| Forward gears | 8correct |
|---|---|
| Reverse gears | 2correct |
| System voltage | 12 Vcorrect |
Working data
| Pump flow | 17 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 43.2 lcorrect |
| Fuel tank capacity | 90.1 lcorrect |
Where this model stands
Power-to-weight ratio: 19.9 kW/t (56 kW / 2.8 t)
Power class: Universal (40–100 hp)
Stronger than 54% of the tractors in the register — out of 15,240 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the ITM 285 have?
The ITM 285 delivers 76 hp.
How much does the ITM 285 weigh?
The unladen weight is 2,812 kg.
What engine does the ITM 285 have?
4 cylinders, 4,061 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
