ITM 240 Utility
Series: Other models
The ITM 240 is a tractor from ITM. The three-cylinder engine, displacing 2.5 litres, produces 48 hp (35 kW). Rated output is reached at 2,250 rpm, so it works in the lower rev range.
It is 1.80 m wide. Unladen weight is 1,711 kg.
Within the range, rated power spans from 47.7 to 113 hp; with 47.7 hp, the 240 sits at the bottom end. The next one up is the 285 with 76 hp.
Technical data
Engine
| Engine model | AD3-152correct |
|---|---|
| Power | 47.7 hp (35 kW)correct |
| Rated speed | 2,250 rpmcorrect |
| Torque | 173correct |
| Speed at max. torque | 1,250 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 2,500.7 cm³correct |
| Coolant capacity | 10.2 lcorrect |
| Engine oil capacity | 31 lcorrect |
Dimensions and weights
| Width | 1,801.4correct |
|---|---|
| Wheelbase | 1,892.8correct |
| Unladen weight | 1,711 kgcorrect |
Drivetrain and chassis
| Gearbox type | sliding spurcorrect |
|---|---|
| System voltage | 12 Vcorrect |
Working data
| Pump flow | 17 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 6.1 lcorrect |
| Fuel tank capacity | 48.1 lcorrect |
Origin and approval
| Version | 2WDcorrect |
|---|
Where this model stands
Power-to-weight ratio: 20.5 kW/t (35 kW / 1.7 t)
Power class: Universal (40–100 hp)
Stronger than 33% of the tractors in the register — out of 15,240 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the ITM 240 have?
The ITM 240 delivers 47.7 hp.
How much does the ITM 240 weigh?
The unladen weight is 1,711 kg.
What engine does the ITM 240 have?
3 cylinders, 2,501 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
