Intem EG-80M2-2
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Intem – other models: the collective page of MEPS-registered three-phase motors outside the named ranges, frame sizes 80 to 315, 0.75 to 200 kW, 2- to 8-pole, 415 V, IP55 throughout
This page gathers the three-phase motors carried in the Australian energy-efficiency register under the Intem brand, which the register does not assign to a named range. No reliable information is available on Intem's headquarters or group ownership; in the register the brand appears purely as a supplier of IEC standard motors. The type designations follow the scheme EG-frame size-pole count, sometimes with an extra digit for a winding variant, e.g. EG-100L-2 or EG-160M1-2; the further meaning of the extra digits cannot be reliably established from the dump.
Read on 3 more paragraphs
The register lists here 103 versions with 0.75 to 200 kW, two- to eight-pole, all rated for 415 V. Full-load efficiencies run between 72.6 and 95.42%, with the 75%-load figures in a similar range, reaching close to 95% in places. All 103 motors are built to protection rating IP55, frame sizes run from 80 to 315 under IEC, manufactured throughout in China and tested under the older Legacy standard AS/NZS 1359.5:2000 with test method B. None of the 103 motors is classified under the Australian High Efficiency Level. Mounting codes are dominated by the broad foot form B3/B5/B6/B7/B8/V1/V3/V5/V6, alongside an even wider combination with B14, B35 and vertical forms V15 to V36, and the plain foot form B3/V1.
The page thus covers a broad IEC standard-motor programme of the kind used in industry for pumps, fans, conveyors and compressors; consistent manufacture in China and the uniform 415 V supply point to a catalogue programme reaching the Australia-Pacific market through various distributors.
When buying used, what matters is bearing condition and a checked insulation resistance of the winding, visible overheating marks on the terminal box and fan cover, the condition of shaft and key, and a legible nameplate with frame size, pole count and efficiency class; since none of the motors carries a High Efficiency Level certification, for continuous duty it is worth comparing against IE2/IE3 alternatives. Spares depend on the distribution channel.
Sources: Kennwerte der Modelle Intem (weitere Modelle, MEPS-Registrierungen)
Technical data
Engine
| Rated output | 1.1 kWcorrect |
|---|
Dimensions and weights
| Weight | 17 kgcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP55correct |
| Frame size | 80 M (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B6, B7, B8, B14, B35, V1, V3, V5, V6, V15, V18, V19, V36correct |
| Efficiency at full load | 76.59 %correct |
| Efficiency at 75 % load | 76.89 %correct |
| Efficiency at half load | 65.89 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2000 (Legacy)correct |
|---|---|
| Test method | AS 1359.102.1:1997correct |
Frequently asked questions
How much power does the Intem EG-80M2-2 have?
The Intem EG-80M2-2 delivers 1.1 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 24 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
