Intem EG-280M-8

Series: Other models

Source: https://www.intem.ma/index.html

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Intem EG-280M-8 is a three-phase induction motor. The rated output is 45 kW. The motor is eight-pole, which at 50 Hz gives a synchronous speed of 750 rpm. The rated voltage is 415 V. The housing is frame size 280 M in foot-mounted form. The protection class is IP55. The efficiency is 92 per cent at full load, 92 per cent at 75 per cent load and 90 per cent at half load. The motor weighs 562 kg. At full load it delivers 580.74 Nm. Mounting arrangements to IEC 60034-7: B3 and V1. The motor is built in China. The values are recorded in the Australian MEPS registration under standard AS/NZS 1359.5:2000 (Legacy); measured to AS 1359.102.1:1997. Rated output across the Intem range ranges from 0.75 to 200 kW; the EG-280M-8 sits in the lower part of that range with 45 kW. Its immediate neighbours are the EG-280S-8 below it with 37 kW and the EG-250M-2 above it with 55 kW. 103 Intem models are on record. The model is listed under Electric motors. 24 verified figures from 1 source are on file.

Technical data

Engine

Rated output45 kWcorrect

Dimensions and weights

Weight562 kgcorrect

Electrical data

Rated voltage415 Vcorrect
Number of poles8correct
Protection classIP55correct
Frame size280 M (foot)correct
Mounting (IEC 60034-7)B3, V1correct
Efficiency at full load92.01 %correct
Efficiency at 75 % load92 %correct
Efficiency at half load90 %correct

Origin and approval

Country of manufactureChinacorrect
Standard appliedAS/NZS 1359.5:2000 (Legacy)correct
Test methodAS 1359.102.1:1997correct

Frequently asked questions

How much power does the Intem EG-280M-8 have?

The Intem EG-280M-8 delivers 45 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
