Hoyer HMC3 225M-4

Series: HMC3

Source: https://www.hoyer.de/news/die-logische-loesung-fuer-die-logi

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Hoyer HMC3 225M-4 is a three-phase induction motor built by Hoyer. The rated output is 45 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The rated voltage is 400 V. The housing is frame size 225 M in foot-mounted form. The efficiency is 94.2 per cent at full load, 94.7 per cent at 75 per cent load and 93.5 per cent at half load. The motor is built in China. The values are recorded in the Australian MEPS registration under the GEMS Determination 2019; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the Hoyer range ranges from 0.75 to 160 kW; the HMC3 225M-4 sits in the lower part of that range with 45 kW. Its immediate neighbours are the HMC3 250M-6 below it with 37 kW and the HMC2 250M-2 above it with 55 kW. 97 Hoyer models are on record. The model is listed under Electric motors. 21 verified figures from 1 source are on file.

Technical data

Engine

Rated output45 kWcorrect

Electrical data

Rated voltage400 Vcorrect
Number of poles4correct
Protection classIP23, IP44, IP55, IP56, IP57, IP65, IP66correct
Frame size225 M (foot)correct
Mounting (IEC 60034-7)B3, B5, B6, B7, B8, B14, B35, V1, V3, V5, V6, V18, V19correct
Efficiency at full load94.22 %correct
Efficiency at 75 % load94.68 %correct
Efficiency at half load93.53 %correct

Origin and approval

Country of manufactureChinacorrect
Standard appliedGreenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct
Test methodIEC 60034-2-1 (Edition 2.0)correct

Frequently asked questions

How much power does the Hoyer HMC3 225M-4 have?

The Hoyer HMC3 225M-4 delivers 45 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
