Hitachi LX150 Super

Series: Hitachi Wheel Loader

Source: https://www.landwirt.com/baumaschinen/radlader/hitachi/land-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the LX150 Super, Hitachi offers a model from the Hitachi Wheel Loader series. The engine delivers 126.8 kW, has 6 cylinders, with a displacement of 7,636.4 cm³. Torque is 787.1 Nm. Rated speed is 2,200 rpm. The unladen weight is 16,057.2 kg. The wheelbase measures 3,200.4 mm. Ground clearance is 487.7 mm. The tank holds 284.3 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,300 rpm. The pump delivers 263.1 l/min. The hydraulic tank holds 115.1 litres. The cooling system holds 28.8 litres. The electrical system runs on 12 V. The engine fitted is the 6076A. Tyre size: 23,5x25. The Hitachi Wheel Loader series covers 29 models. Rated output within it ranges from 16.4 to 331.1 kW; the LX150 Super sits in the lower part of that range with 126.8 kW. Its immediate neighbours are the LX170E below it with 123 kW and the ZW180 above it with 127.5 kW. 347 Hitachi models across 20 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine model6076Acorrect
Power126.8 kWcorrect
Rated speed2,200 rpmcorrect
Torque787.1correct
Speed at max. torque1,300 rpmcorrect
Cylinders6correct
Displacement7,636.4 cm³correct
Aspirationturbochargedcorrect
Coolant capacity28.8 lcorrect

Dimensions and weights

Wheelbase3,200.4correct
Ground clearance487.7correct
Unladen weight16,057.2 kgcorrect

Drivetrain and chassis

Gearbox typePower Shiftcorrect
Forward gears4correct
Reverse gears3correct
Tyre size23.5x25correct
System voltage12 Vcorrect

Working data

Pump flow263.1 l/mincorrect
Hydraulic oil capacity115.1 lcorrect
Fuel tank capacity284.3 lcorrect

Other data

Height3,422.9correct

Where this model stands

Power-to-weight ratio: 7.9 kW/t (127 kW / 16.1 t)

Stronger than 65% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Hitachi LX150 Super have?

The Hitachi LX150 Super delivers 127 kW.

How much does the Hitachi LX150 Super weigh?

The unladen weight is 16,057 kg.

What engine does the Hitachi LX150 Super have?

6 cylinders, 7,636 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
