Hebem FF-L112S-4
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hebem – other models: the collective page of MEPS-registered three-phase motors outside the named ranges, frame size 112, 2.2 to 4.5 kW, four-pole, manufactured in China
Hebem is a manufacturer name carried in the Australian energy-efficiency register for three-phase motors; no further confirmed company data is available. This page gathers the Hebem motors the register (GEMS/MEPS) could not assign to a named range. The model designations FF-L112M, FF-L112M1, FF-L112S, FF112M and FF112S recognisably follow a uniform scheme of frame size 112 and a code for build length (S, M, M1), all in four-pole form.
Read on 3 more paragraphs
The register lists here 5 versions with 2.2 to 4.5 kW rated output, all four-pole, at voltages from 400 V up to the multi-range version 400/440/460 V. Full-load efficiency ranges from 86 to 88.84%, and at 75% load from 85.2 to 89.74%. All five motors carry protection rating IP55 and the uniform frame size 112. Testing followed the 2019 and 2012 GEMS determinations with test method A; three of the five versions reach the 2005 High Efficiency Level (roughly IE2), two remain unclassified. China is recorded as the manufacturing country, and the mounting form is B5 on four motors and B30 on one.
Motors of this frame size and power class are a typical drive for small to mid-size pumps, fans, conveyor belts and machine tools in general industry; the tight focus on a single frame size with a constant pole count points to a range built for a narrowly defined application group.
When buying used, bearing condition and a checked insulation resistance of the winding, visible corrosion or overheating marks on the terminal box and fan cover, the condition of shaft and key, and a legible nameplate with frame size, pole count and efficiency class matter; on the 400/440/460 V multi-range voltage, it is worth checking the correct connection method in the terminal box. Spares run through the relevant Hebem distribution.
Sources: Kennwerte der Modelle Hebem (weitere Modelle, MEPS-Registrierungen)
Technical data
Engine
| Rated output | 3 kWcorrect |
|---|
Dimensions and weights
| Weight | 29 kgcorrect |
|---|
Electrical data
| Rated voltage | 400/440/460 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | IP55correct |
| Frame size | 112 S (foot)correct |
| Mounting (IEC 60034-7) | B5correct |
| Efficiency at full load | 87.81 %correct |
| Efficiency at 75 % load | 88.8 %correct |
| Efficiency at half load | 88.4 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | AS/NZS 1359.102.3:2000correct |
Frequently asked questions
How much power does the Hebem FF-L112S-4 have?
The Hebem FF-L112S-4 delivers 3 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 24 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
