Haulotte HTL4014

Series: Haulotte Telescopic Forklift

Source: https://www.kleinanzeigen.de/s-anzeige/teleskopstapler-haulo

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Haulotte Telescopic Forklift series from Haulotte includes the HTL4014. The engine delivers 101.9 hp (74.9 kW), with a displacement of 6,617.1 cm³. Torque is 390.1 Nm. Rated speed is 2,300 rpm. The wheelbase measures 2,901.7 mm. Ground clearance is 502.9 mm. The tank holds 132.9 litres. Maximum torque is reached at 1,500 rpm. The pump delivers 150.3 l/min. The hydraulic tank holds 115.1 litres. Working pressure is 260 bar. The electrical system runs on 12 V. The engine fitted is the BF04M2012. Tyre size: 18-22,5 TM R4 6PR. The Haulotte Telescopic Forklift series covers 7 models. Rated output within it ranges from 75.3 to 112.9 hp; the HTL4014 sits in the upper part of that range with 101.9 hp. Its immediate neighbours are the HTL9055 below it with 75.3 hp and the HTL11532 above it with 112.9 hp. 101 Haulotte models across 10 series are on record. The model is listed under Telehandlers. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine modelBF04M2012correct
Power101.9 hp (74.9 kW)correct
Rated speed2,300 rpmcorrect
Torque390.1correct
Speed at max. torque1,500 rpmcorrect
Displacement6,617.1 cm³correct
Aspirationturbochargedcorrect

Dimensions and weights

Wheelbase2,901.7correct
Ground clearance502.9correct

Drivetrain and chassis

Gearbox typehydrostatic transmissioncorrect
Tyre size18-22.5 TM R4 6PRcorrect
System voltage12 Vcorrect

Working data

Pump flow150.3 l/mincorrect
Hydraulic oil capacity115.1 lcorrect
Hydraulic pressure260correct
Fuel tank capacity132.9 lcorrect

Frequently asked questions

How much power does the Haulotte HTL4014 have?

The Haulotte HTL4014 delivers 102 hp.

What engine does the Haulotte HTL4014 have?

6,617 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
