Haulmax 3900D

Series: Haulmax Articulated Dump Truck

Source: http://uncle-vova.com/card/haulmax-3900t-off-highway-truck-t

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Haulmax 3900D belongs to the Haulmax Articulated Dump Truck series. The engine delivers 797.9 hp (551.8 kW), has 12 cylinders, with a displacement of 27,001 cm³. Rated speed is 2,000 rpm. The machine is 4,330 mm high. The wheelbase measures 7,860.8 mm. Ground clearance is 618.7 mm. Top speed is 75.3 km/h. The tank holds 1,000.1 litres. The gearbox has 7 forward gears. There are also 1 reverse gears. The hydraulic tank holds 450.1 litres. The cooling system holds 175.3 litres. The oil fill is 95 litres. The engine fitted is the C27 Acert. Tyre size: 21,00xR35. Rated output within this group ranges from 20.3 to 4,126.5 hp; the 3900D sits in the lower part of that range with 797.9 hp. Its immediate neighbours are the D475A-2 below it with 791.8 hp and the HD780 above it with 811.1 hp. Rated output within this group ranges from 14.9 to 2,513 kW; here the 3900D sits in the lower part of that range with 551.8 kW.

Technical data

Engine

Engine model	C27 Acertcorrect
Power	797.9 hp (551.8 kW)correct
Rated speed	2,000 rpmcorrect
Cylinders	12correct
Displacement	27,001 cm³correct
Coolant capacity	175.3 lcorrect
Engine oil capacity	95 lcorrect

Dimensions and weights

Length	14,618.2correct
Width	4,200.1correct
Height	4,330 mmcorrect
Wheelbase	7,860.8correct
Ground clearance	618.7correct

Drivetrain and chassis

Forward gears	7correct
Reverse gears	1correct
Tyre size	21.00xR35correct
Top speed	75.3 km/hcorrect

Working data

Hydraulic oil capacity	450.1 lcorrect
Fuel tank capacity	1,000.1 lcorrect

Frequently asked questions

How much power does the Haulmax 3900D have?

The Haulmax 3900D delivers 798 hp.

What engine does the Haulmax 3900D have?

12 cylinders, 27,001 cm³ displacement.

How fast does the Haulmax 3900D go?

Top speed is 75.3 km/h.

What are the dimensions of the Haulmax 3900D?

14,618 mm × 4,200 mm × 4,330 mm.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
