Hatz 2M41Z

Built: 2012-2014 · Series: Other models

Source: https://www.diagramboard.com/hatz-2m41z-wiring-schematic-dia

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 2M41Z comes from Hatz. Production: 2012-2014. The fuel is 7-15 ppm Ultra Low Sulfur Diesel. The rated output is 20 kW. The engine is naturally aspirated. The engine meets emissions stage Interim Tier 4. Fuel reaches the combustion chamber through direct injection. It is a four-stroke diesel engine. The cylinders are arranged in line. Rated output across the Hatz range ranges from 2 to 39 kW; the 2M41Z sits in the middle of that range with 20 kW. Its immediate neighbours are the 2L41C below it with 19 kW and the 3L43C above it with 21 kW. 126 Hatz models across 8 series are on record. The model is listed under Non-road diesel engines. 24 verified figures from 1 source are on file.

Technical data

Engine

Engine code2M41Z-ICFN-2350correct
Engine familyCHZXL3.43C41correct
Engine familiesCHZXL3.43C41correct
Fuel7-15 ppm Ultra Low Sulfur Dieselcorrect
Rated output20 kWcorrect
Power band19<=kW<37correct
Rated speed2,350 rpmcorrect
Maximum torque81.7 N·mcorrect
Speed at max. torque2,350 rpmcorrect
Cylinders2correct
Cylinder layoutin linecorrect
Bore102 mmcorrect
Stroke105 mmcorrect
Operating cyclefour-stroke dieselcorrect
Injectiondirect injectioncorrect
Aspirationnaturally aspiratedcorrect
Emissions stageInterim Tier 4correct

Origin and approval

Version2M41Z-ICFN-2350correct
Built from2012correct
Built to2012correct
Model year from2012correct
Model year to2019correct
