Hatz 1D42C

Built: 2012-2015 · Series: Other models

Source: https://parts.hatz.com/nach-motorenfamilie/b-serie/ parts.h

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Hatz 1D42C is a machine built by Hatz. Production: 2012-2015. The fuel is 7-15 ppm Ultra Low Sulfur Diesel. The rated output is 4 kW. The engine is naturally aspirated. The engine meets emissions stage Tier 4 (Final or Phase In). Fuel reaches the combustion chamber through direct injection. It is a four-stroke diesel engine. The cylinders are arranged in line. Rated output across the Hatz range ranges from 2 to 39 kW; the 1D42C sits at the bottom of that range with 4 kW. Its immediate neighbours are the B20-3600 below it with 3 kW and the 1B40 T / U above it with 5 kW. 126 Hatz models across 8 series are on record. The model is listed under Non-road diesel engines. 24 verified figures from 1 source are on file.

Technical data

Engine

Engine codeD42C-2000correct
Engine familyCHZXL.445C42correct
Engine familiesCHZXL.445C42correct
Fuel7-15 ppm Ultra Low Sulfur Dieselcorrect
Rated output4 kWcorrect
Power bandkW<8correct
Rated speed2,000 rpmcorrect
Maximum torque17.7 N·mcorrect
Speed at max. torque2,000 rpmcorrect
Cylinders1correct
Cylinder layoutin linecorrect
Bore90 mmcorrect
Stroke70 mmcorrect
Operating cyclefour-stroke dieselcorrect
Injectiondirect injectioncorrect
Aspirationnaturally aspiratedcorrect
Emissions stageTier 4 (Final or Phase In)correct

Origin and approval

VersionD42C-2000correct
Built from2012correct
Built to2012correct
Model year from2012correct
Model year to2018correct

Frequently asked questions

How much power does the Hatz 1D42C have?

The Hatz 1D42C delivers 4 kW.

When was the Hatz 1D42C built?

Production years: 2012-2015.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 24 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
