Hatz 1D90VE

Q: How much power does the Hatz 1D90VE have?

The Hatz 1D90VE delivers 11 kW.

Built: 2023-2023 · Series: Other models

Source: https://parts.hatz.com/hatz-original-teil-vs-nachbauten-leis

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 1D90VE comes from Hatz. Production: 2023. The fuel is 7-15 ppm Ultra Low Sulfur Diesel. The rated output is 11 kW. The engine is naturally aspirated. The engine meets emissions stage Tier 4 (Final or Phase In). Fuel reaches the combustion chamber through direct injection. It is a four-stroke diesel engine. The cylinders are arranged in line. Rated output across the Hatz range ranges from 2 to 39 kW; the 1D90VE sits in the lower part of that range with 11 kW. Its immediate neighbours are the 1D90E S/Z below it with 10 kW and the 2M41 above it with 15 kW. 126 Hatz models across 8 series are on record. The model is listed under Non-road diesel engines. 24 verified figures from 1 source are on file.

Technical data

Engine

Engine code	3000-10.5-cscorrect
Engine family	RHZXL.722M92; PHZXL.722M92; THZXL.722M92; SHZXL.722M92correct
Engine families	RHZXL.722M92; PHZXL.722M92; THZXL.722M92; SHZXL.722M92correct
Fuel	7-15 ppm Ultra Low Sulfur Dieselcorrect
Rated output	11 kWcorrect
Power band	8<=kW<19correct
Rated speed	3,000 rpmcorrect
Maximum torque	33 N·mcorrect
Speed at max. torque	3,000 rpmcorrect
Cylinders	1correct
Cylinder layout	in linecorrect
Bore	104 mmcorrect
Stroke	85 mmcorrect
Operating cycle	four-stroke dieselcorrect
Injection	direct injectioncorrect
Aspiration	naturally aspiratedcorrect
Emissions stage	Tier 4 (Final or Phase In)correct

Origin and approval

Version	3000-10.5-cscorrect
Built from	2023correct
Built to	2026correct
Model year from	2023correct
Model year to	2026correct

Frequently asked questions

How much power does the Hatz 1D90VE have?

The Hatz 1D90VE delivers 11 kW.

When was the Hatz 1D90VE built?

Production years: 2023.

What to check before buying

Match the data plate against the order: frame size, mounting and rating have to agree.
For used units, ask about winding condition and bearing play.
Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
