Start › Mobile & rough terrain cranes › Grove › RT865BXL

Grove RT865BXL

Series: Grove Rough Terrain Crane

Source: https://www.profi.de/aktuell/neuheiten/fendt-prasentiert-neu

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the RT865BXL, Grove offers a model from the Grove Rough Terrain Crane series. The engine delivers 253 hp (186.1 kW), has 6 cylinders, with a displacement of 8,300 cm³. The engine comes from Cummins. Torque is 1,077.1 Nm. Rated speed is 2,200 rpm. The unladen weight is 46,648 kg. Ground clearance is 365.8 mm. The tank holds 303.2 litres. The gearbox has 6 forward gears. There are also 6 reverse gears. Maximum torque is reached at 1,500 rpm. The hydraulic tank holds 757.1 litres. The electrical system runs on 24 V. The engine fitted is the 6CTA 8,3L. Tyre size: 33,25X29-32PR. The Grove Rough Terrain Crane series covers 81 models. Rated output within it ranges from 106.1 to 608.3 hp; the RT865BXL sits in the lower part of that range with 253 hp. Its immediate neighbours are the RT770E below it with 243.4 hp and the RT875CC above it with 253.5 hp. 338 Grove models across 8 series are on record. The model is listed under Cranes & access platforms. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine makeCumminscorrect
Engine model6CTA 8.3Lcorrect
Power253 hp (186.1 kW)correct
Rated speed2,200 rpmcorrect
Torque1,077.1correct
Speed at max. torque1,500 rpmcorrect
Cylinders6correct
Displacement8,300 cm³correct
Aspirationturbochargedcorrect

Dimensions and weights

Ground clearance365.8correct
Unladen weight46,648 kgcorrect

Drivetrain and chassis

Gearbox typefull powershift transmissioncorrect
Forward gears6correct
Reverse gears6correct
Tyre size33.25X29-32PRcorrect
System voltage24 Vcorrect

Working data

Hydraulic oil capacity757.1 lcorrect
Fuel tank capacity303.2 lcorrect

Where this model stands

Power-to-weight ratio: 4 kW/t (186 kW / 46.6 t)

Stronger than 43% of the mobile & rough terrain cranes in the register — out of 591 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Grove RT865BXL have?

The Grove RT865BXL delivers 253 hp.

How much does the Grove RT865BXL weigh?

The unladen weight is 46,648 kg.

What engine does the Grove RT865BXL have?

6 cylinders, 8,300 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 19 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
