General Trailers TF 34 VZ
Built: 2003-2003 · Series: Other models
More machines from model year 2003
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
General Trailers – other models: French semi-trailers, successor to Fruehauf, outside the named ranges, 2.7 to 42 t gross vehicle weight, 6.9 to 14.05 m length
General Trailers is a French semi-trailer manufacturer that emerged as the successor to Fruehauf in France; individual model names such as "FRUEHAUF ONCZ 36-324 A" on this page still point directly to that origin. This page gathers the models outside the named ranges, with the type codes ONCR/ONCRS/ONCRK, TF and RC for different body types and the DX series. Body types range from flatbeds through refrigerated and curtainside semi-trailers to box semi-trailers.
Read on 3 more paragraphs
The register lists here 24 versions with gross vehicle weights from 2,700 to 42,000 kg, lengths from 6,900 to 14,050 mm and widths from 2,450 to 2,600 mm.
With gross vehicle weights of up to 42 tonnes, the range covers the classic three-axle standard semi-trailers for long-haul transport, as used by French and southern European hauliers in combined operation with tractor units; General Trailers competes there with Krone, Schmitz Cargobull and Kögel. As the successor brand to Fruehauf, the company benefits from an established name in the French long-haul market.
When buying used, the condition of the chassis and kingpin matters, the brake system with ABS/EBS, axles and air suspension, the condition of the tarpaulin or flatbed depending on the body type, and the function of the landing legs. Parts for axles, brakes and lighting are available through the general semi-trailer parts trade, specific chassis parts more through workshops specialising in French trailers.
Sources: Kennwerte der Modelle General Trailers (weitere Modelle)
Technical data
Dimensions and weights
| Length | 14,000 mmcorrect |
|---|---|
| Width | 2,600 mmcorrect |
| Wheelbase | 9,600 mmcorrect |
| Unladen weight | 11,120 kgcorrect |
| Gross vehicle weight | 38,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the General Trailers TF 34 VZ weigh?
The unladen weight is 11,120 kg.
What is the gross vehicle weight of the General Trailers TF 34 VZ?
38,000 kg.
Up to what speed is the General Trailers TF 34 VZ approved?
Approved up to 100 km/h.
What are the dimensions of the General Trailers TF 34 VZ?
14,000 mm × 2,600 mm.
When was the General Trailers TF 34 VZ built?
Production years: 2003.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
