General Electric 5KFS162XAA2006

Series: Other models

The photo shows the 5KFS162XAA2007 from the same series. Source: http://commons.wikimedia.org/wiki/File:General_Wesley_Clark_

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The General Electric 5KFS162XAA2006 is a three-phase induction motor. The rated output is 11 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The housing is frame size 160 M in foot-mounted form. The protection class is IP55. The efficiency is 92.7 per cent at full load, 93.4 per cent at 75 per cent load and 93.3 per cent at half load. The motor weighs 143 kg. The mounting arrangement to IEC 60034-7 is B3. The motor is built in Mexico. The data is based on the Australian MEPS registration under the GEMS Determination 2012; measured to IEEE 112-B(USA). Rated output across the General Electric range ranges from 0.75 to 90 kW; the 5KFS162XAA2006 sits at the bottom of that range with 11 kW. Its immediate neighbours are the 5K132SBIM2013 below it with 5.5 kW and the 5K160LBIM2013 above it with 15 kW. 16 General Electric models across 2 series are on record. The model is listed under Electric motors. 23 verified figures from 1 source are on file.

Technical data

Engine

Rated output11 kWcorrect

Dimensions and weights

Weight143 kgcorrect

Electrical data

Number of poles4correct
Protection classIP55correct
Frame size160 M (foot)correct
Mounting (IEC 60034-7)B3correct
Efficiency at full load92.7 %correct
Efficiency at 75 % load93.4 %correct
Efficiency at half load93.3 %correct

Origin and approval

Country of manufactureMexicocorrect
Standard appliedGreenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct
Test methodIEEE 112-B(USA)correct

Frequently asked questions

How much power does the General Electric 5KFS162XAA2006 have?

The General Electric 5KFS162XAA2006 delivers 11 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
