General Electric 5K100LBIM2013

The General Electric 5K100LBIM2013 is a three-phase induction motor from the General Electric range. The rated output is 2.2 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The rated voltage is 415 V. The housing is frame size 100 L in foot-mounted form. The protection class is IP55. The efficiency is 79.9 per cent at full load, 80.7 per cent at 75 per cent load and 78.8 per cent at half load. The motor weighs 40 kg. At full load it delivers 14.8 Nm. The mounting arrangement to IEC 60034-7 is B3. The motor is built in China. The data is based on the Australian MEPS registration under standard AS/NZS 1359.5:2000 (Legacy); measured to IEEE 112-B(USA). Rated output across the General Electric range ranges from 0.75 to 90 kW; the 5K100LBIM2013 sits at the bottom of that range with 2.2 kW. Its immediate neighbours are the 5K90LFIM2013 below it with 1.5 kW and the 5K112MBIM2027 above it with 4 kW. 16 General Electric models across 2 series are on record. The model is listed under Electric motors. 24 verified figures from 1 source are on file.
