Gehl CTL60

Series: Gehl Multi Terrain Loader

Source: https://www.truck1.eu/construction-machinery/skid-steer-load

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Gehl CTL60 is a model in the Gehl Multi Terrain Loader series. The engine delivers 49.2 kW, has 4 cylinders, with a displacement of 3,318.4 cm³. Rated speed is 2,450 rpm. The unladen weight is 3,400.6 kg. Ground clearance is 310.1 mm. The tank holds 75.3 litres. Maximum torque is reached at 1,600 rpm. The hydraulic tank holds 38.6 litres. Working pressure is 206 bar. The cooling system holds 11.4 litres. The oil fill is 10.2 litres. The electrical system runs on 12 V. The engine fitted is the 4TNV98. The Gehl Multi Terrain Loader series covers 8 models. Rated output within it ranges from 49.2 to 72.3 kW; the CTL60 sits at the bottom of that range with 49.2 kW. Its immediate neighbours are the CTL65 above it with 50 kW. 72 Gehl models across 9 series are on record. The model is listed under Wheel loaders. 16 verified figures from 1 source are on file.

Technical data

Engine

Engine model4TNV98correct
Power49.2 kWcorrect
Rated speed2,450 rpmcorrect
Speed at max. torque1,600 rpmcorrect
Cylinders4correct
Displacement3,318.4 cm³correct
Aspirationnaturalcorrect
Coolant capacity11.4 lcorrect
Engine oil capacity10.2 lcorrect

Dimensions and weights

Ground clearance310.1correct
Unladen weight3,400.6 kgcorrect

Drivetrain and chassis

System voltage12 Vcorrect

Working data

Hydraulic oil capacity38.6 lcorrect
Hydraulic pressure206correct
Fuel tank capacity75.3 lcorrect

Other data

Height2,124.5correct

Where this model stands

Power-to-weight ratio: 14.5 kW/t (49 kW / 3.4 t)

Stronger than 17% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Gehl CTL60 have?

The Gehl CTL60 delivers 49.2 kW.

How much does the Gehl CTL60 weigh?

The unladen weight is 3,401 kg.

What engine does the Gehl CTL60 have?

4 cylinders, 3,318 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
