Gehl AWS680

Series: Gehl Wheel Loader

Source: https://www.kleinanzeigen.de/s-anzeige/gehl-radlader-tiefgar

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Gehl AWS680 belongs to the Gehl Wheel Loader series. The engine delivers 76 hp (55.9 kW), has 4 cylinders, with a displacement of 3,113.5 cm³. Torque is 269.8 Nm. Rated speed is 2,300 rpm. The unladen weight is 5,449.9 kg. The wheelbase measures 2,051.3 mm. Ground clearance is 320 mm. The tank holds 80.3 litres. Maximum torque is reached at 1,600 rpm. The pump delivers 70 l/min. The hydraulic tank holds 85.2 litres. The electrical system runs on 12 V. The engine fitted is the BF4M 2011. The Gehl Wheel Loader series covers 8 models. Rated output within it ranges from 20.3 to 76 hp; the AWS680 sits at the top of that range with 76 hp. Its immediate neighbours are the AWS480T below it with 59.8 hp. 72 Gehl models across 9 series are on record. The model is listed under Wheel loaders. 16 verified figures from 1 source are on file.

Technical data

Engine

Engine modelBF4M 2011correct
Power76 hp (55.9 kW)correct
Rated speed2,300 rpmcorrect
Torque269.8correct
Speed at max. torque1,600 rpmcorrect
Cylinders4correct
Displacement3,113.5 cm³correct

Dimensions and weights

Wheelbase2,051.3correct
Ground clearance320correct
Unladen weight5,449.9 kgcorrect

Drivetrain and chassis

System voltage12 Vcorrect

Working data

Pump flow70 l/mincorrect
Hydraulic oil capacity85.2 lcorrect
Fuel tank capacity80.3 lcorrect

Other data

Height2,712.7correct

Where this model stands

Power-to-weight ratio: 10.3 kW/t (56 kW / 5.4 t)

Stronger than 25% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Gehl AWS680 have?

The Gehl AWS680 delivers 76 hp.

How much does the Gehl AWS680 weigh?

The unladen weight is 5,450 kg.

What engine does the Gehl AWS680 have?

4 cylinders, 3,114 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
