Start › Wheel loaders › Gehl › AWS280

Gehl AWS280

Series: Gehl Wheel Loader

Source: https://www.kleinanzeigen.de/s-anzeige/gehl-radlader-tiefgar

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Gehl AWS280 is a model in the Gehl Wheel Loader series. The engine delivers 39.5 hp (29.1 kW), has 4 cylinders, with a displacement of 2,191 cm³. Torque is 143 Nm. Rated speed is 2,400 rpm. The unladen weight is 3,200.1 kg. The wheelbase measures 1,752.6 mm. Ground clearance is 320 mm. The tank holds 60.2 litres. Maximum torque is reached at 1,600 rpm. The pump delivers 70 l/min. The hydraulic tank holds 65.1 litres. The electrical system runs on 12 V. The engine fitted is the 4TNV88. The Gehl Wheel Loader series covers 8 models. Rated output within it ranges from 20.3 to 76 hp; the AWS280 sits in the lower part of that range with 39.5 hp. Its immediate neighbours are the AVANTAGE below it with 20.3 hp and the AWS480 above it with 59.8 hp. 72 Gehl models across 9 series are on record. The model is listed under Wheel loaders. 16 verified figures from 1 source are on file.

Technical data

Engine

Engine model4TNV88correct
Power39.5 hp (29.1 kW)correct
Rated speed2,400 rpmcorrect
Torque143correct
Speed at max. torque1,600 rpmcorrect
Cylinders4correct
Displacement2,191 cm³correct

Dimensions and weights

Wheelbase1,752.6correct
Ground clearance320correct
Unladen weight3,200.1 kgcorrect

Drivetrain and chassis

System voltage12 Vcorrect

Working data

Pump flow70 l/mincorrect
Hydraulic oil capacity65.1 lcorrect
Fuel tank capacity60.2 lcorrect

Other data

Height2,340.9correct

Where this model stands

Power-to-weight ratio: 9.1 kW/t (29 kW / 3.2 t)

Stronger than 4% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Gehl AWS280 have?

The Gehl AWS280 delivers 39.5 hp.

How much does the Gehl AWS280 weigh?

The unladen weight is 3,200 kg.

What engine does the Gehl AWS280 have?

4 cylinders, 2,191 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 16 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →

Other models in this series

140

340

540

AVANTAGE

AWS480

AWS480T

AWS680
