Fendt 514 4WD
Series: Other models
As a tractor, the Fendt 514 belongs to the Fendt 4WD Tractor series. 135 hp (107 kW) is what the four-cylinder engine gets out of 22.1 litres. Rated output is reached at 1,900 rpm, so it works in the lower rev range.
Top speed is 40 km/h. Dimensions are 4.45 m by 2.50 m. At 10,500 kg, it puts weight behind its pulling power — a good 78 kilograms per hp.
The engine is water-cooled. Within the range, rated power spans from 65.3 to 500 hp; with 135 hp, the 514 sits in the mid-field. Directly alongside are the 712 with 131 hp below and the 414 with 146 hp above.
Technical data
Engine
| Power | 134.6 hp (107 kW)correct |
|---|---|
| Rated speed | 1,900 rpmcorrect |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 22,057 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,453.1correct |
|---|---|
| Width | 2,502.4correct |
| Wheelbase | 2,560.1correct |
| Ground clearance | 545.1correct |
| Unladen weight | 10,500 kgcorrect |
Drivetrain and chassis
| Top speed | 40.1 km/hcorrect |
|---|---|
| System voltage | 14.4 Vcorrect |
Working data
| Pump flow | 109.8 l/mincorrect |
|---|---|
| Fuel tank capacity | 298.3 lcorrect |
Other data
| Height | 2,965.7correct |
|---|
Where this model stands
Power-to-weight ratio: 10.2 kW/t (107 kW / 10.5 t)
Power class: Large (100–180 hp)
Stronger than 83% of the tractors in the register — out of 15,240 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Fendt 514 have?
The Fendt 514 delivers 135 hp.
How much does the Fendt 514 weigh?
The unladen weight is 10,500 kg.
What engine does the Fendt 514 have?
4 cylinders, 22,057 cm³ displacement.
How fast does the Fendt 514 go?
Top speed is 40.1 km/h.
What are the dimensions of the Fendt 514?
4,453 mm × 2,502 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
