Faun ATF 60-3
Built: 2003-2010 · Series: ATF
More machines from model year 2003
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Faun ATF – all-terrain mobile cranes from the German manufacturer of Lauf: 240 to 390 kW, six- and eight-cylinder engines up to 16 litres, axle configurations G-2 to G-5, lift capacities up to 220 tonnes
This page gathers mobile cranes of the ATF range from Faun, the German manufacturer of Lauf an der Pegnitz near Nuremberg, whose crane business has belonged to Tadano since 2019. ATF stands for "All Terrain Faun" and denotes the all-terrain telescopic cranes that replaced the earlier Krupp and Faun crane range from the 1980s onward. The type designation gives the maximum lift capacity in tonnes before the G and the number of axles after it – the ATF 220G-5 a crane with 220 tonnes lift capacity on five axles, the ATF 40G-2 a compact two-axle crane with 40 tonnes.
Read on 3 more paragraphs
The register lists 22 versions with 240 to 390 kW from six- to eight-cylinders of 6,374 to 15,982 cm³, operating weights from 23,750 to 60,000 kg, gross weights from 24,000 to 72,000 kg, lengths from 10,170 to 15,980 mm and widths from 2,550 to 3,000 mm.
Faun's mobile cranes are, alongside Liebherr and Grove, one of the established brands in heavy-lift and construction-site work; all-wheel steering and the compact build allow use even on tight sites and on public roads under truck registration.
On used examples of these crane chassis, the operating hours of engine and crane gear, the condition of the telescopic boom and winch, axles and steering, the maintenance history of the hydraulics and the roadworthiness and crane inspection records count; parts run through the Tadano-Faun service network.
Sources: Kennwerte der Modelle Faun ATF, Tadano (Hersteller, vormals Faun)
Technical data
Engine
| Power | 240 kWcorrect |
|---|---|
| Cylinders | 6correct |
| Displacement | 7,201 cm³correct |
Dimensions and weights
| Length | 11,940 mmcorrect |
|---|---|
| Width | 2,850 mmcorrect |
| Wheelbase | 4,630 mmcorrect |
| Unladen weight | 35,750 kgcorrect |
| Gross vehicle weight | 36,000 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|
Where this model stands
Power-to-weight ratio: 6.7 kW/t (240 kW / 35.8 t)
Stronger than 38% of the trucks over 7.5 t in the register — out of 25,424 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Faun ATF 60-3 have?
The Faun ATF 60-3 delivers 240 kW.
How much does the Faun ATF 60-3 weigh?
The unladen weight is 35,750 kg.
What is the gross vehicle weight of the Faun ATF 60-3?
36,000 kg.
What engine does the Faun ATF 60-3 have?
6 cylinders, 7,201 cm³ displacement.
What are the dimensions of the Faun ATF 60-3?
11,940 mm × 2,850 mm.
When was the Faun ATF 60-3 built?
Production years: 2003-2010.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 12 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
