Elgi 160M1-2
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
ELGi – other models: the collective page of three-phase motors from the Indian compressor maker outside the named ranges, 3 to 75 kW, 2- to 4-pole, IP55, High Efficiency Level 2018
This page gathers the ELGi three-phase motors the Australian energy-efficiency register (GEMS/MEPS) could not assign to a named range. ELGi Equipments, headquartered in Coimbatore, India, and founded in 1960, is known chiefly as a compressor manufacturer, and the motors recorded in the register serve chiefly to drive its compressors. The model names mostly follow the IEC scheme of frame size and pole count, for example 160L-4 for the four-pole 160L version, alongside internal codes such as X100078.
Read on 3 more paragraphs
The register lists here 29 versions with 3 to 75 kW, two- to four-pole, at a uniform mains voltage of 400 V. Full-load efficiencies range from 87.21 to 95.04% and at 75% load from 86.89 to 94.73%; all 29 versions reach the High Efficiency Level 2018 classification. Frame sizes run from 100 to 280 under IEC, all motors carry protection rating IP55, mounting codes cover B3, B35 and their combination; manufacturing is mainly in China, with a smaller share in India, tested to the GEMS 2019 determinations with test method 2-1-1B.
As a drive for compressors, pumps and other industrial applications, the motor programme complements ELGi's core compressor business; the uniform High Efficiency Level 2018 classification shows a programme aligned with current efficiency requirements.
When buying used, what matters is bearing condition and a checked insulation resistance of the winding, visible overheating marks on the terminal box and fan cover, the condition of shaft and key, and a legible nameplate with frame size, pole count and efficiency class. Spares and service run through the ELGi sales network, particularly where the motor is fitted directly to an ELGi compressor.
Sources: Kennwerte der Modelle ELGi (weitere Modelle, MEPS-Registrierungen), ELGi Equipments (Hersteller)
Technical data
Engine
| Rated output | 11 kWcorrect |
|---|
Electrical data
| Rated voltage | 400 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP55correct |
| Frame size | 160 M (foot)correct |
| Mounting (IEC 60034-7) | B3correct |
| Efficiency at full load | 91.21 %correct |
| Efficiency at 75 % load | 90.83 %correct |
| Efficiency at half load | 89.12 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the Elgi 160M1-2 have?
The Elgi 160M1-2 delivers 11 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
