Ebony CDF22/B3/2

Series: Other models

The photo shows the CDF4/B3/2 from the same series. Source: https://www.kleinanzeigen.de/s-anzeige/elektromotor-b3-b5-od

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

Ebony lists the CDF22/B3/2 as a three-phase induction motor. The rated output is 22 kW. The motor is two-pole, which at 50 Hz gives a synchronous speed of 3,000 rpm. The rated voltage is 415 V. The housing is frame size 180 M in foot-mounted form. The protection class is IP55. The efficiency is 90.6 per cent at full load, 91 per cent at 75 per cent load and 89.2 per cent at half load. The motor weighs 180 kg. At full load it delivers 71.5 Nm. Mounting arrangements to IEC 60034-7: B3, B5, B14, B35 and B34. The motor is built in China. The data is based on the Australian MEPS registration under standard AS/NZS 1359.5:2000 (Legacy); measured to AS 1359.102.1:1997. Rated output across the Ebony range ranges from 0.75 to 22 kW; the CDF22/B3/2 sits at the top of that range with 22 kW. Its immediate neighbours are the CDF18.5/B3/4 below it with 18.5 kW. 34 Ebony models are on record. The model is listed under Electric motors. 24 verified figures from 1 source are on file.

Technical data

Engine

Rated output22 kWcorrect

Dimensions and weights

Weight180 kgcorrect

Electrical data

Rated voltage415 Vcorrect
Number of poles2correct
Protection classIP55correct
Frame size180 M (foot)correct
Mounting (IEC 60034-7)B3, B5, B14, B35, B34correct
Efficiency at full load90.62 %correct
Efficiency at 75 % load90.95 %correct
Efficiency at half load89.15 %correct

Origin and approval

Country of manufactureChinacorrect
Standard appliedAS/NZS 1359.5:2000 (Legacy)correct
Test methodAS 1359.102.1:1997correct
