Dovers 112
Series: Other models
The Dovers 112 is a three-phase induction motor from the Dovers range. The rated output is 1.5 kW. The motor is eight-pole, which at 50 Hz gives a synchronous speed of 750 rpm. The rated voltage is 415 V. The housing is frame size 112 M in foot-mounted form. The protection class is IP55. The efficiency is 75 per cent at full load, 73 per cent at 75 per cent load and 67 per cent at half load. The motor weighs 43 kg. At full load it delivers 19.9 Nm. Mounting arrangements to IEC 60034-7: B3, B35, B34, B5, B14 and V1. The motor is built in China. The values are recorded in the Australian MEPS registration under the GEMS Determination 2012; measured to AS/NZS 1359.102.3:2000. Rated output across the Dovers range ranges from 0.75 to 110 kW; the 112 sits at the bottom of that range with 1.5 kW. Its immediate neighbours are the 100 below it with 1.1 kW and the 132 above it with 2.2 kW. 13 Dovers models are on record. The model is listed under Electric motors. 24 verified figures from 1 source are on file.
Technical data
Engine
| Rated output | 1.5 kWcorrect |
|---|
Dimensions and weights
| Weight | 43 kgcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 8correct |
| Protection class | IP55correct |
| Frame size | 112 M (foot)correct |
| Mounting (IEC 60034-7) | B3, B35, B34, B5, B14, V1correct |
| Efficiency at full load | 75 %correct |
| Efficiency at 75 % load | 73 %correct |
| Efficiency at half load | 67 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|---|
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct |
| Test method | AS/NZS 1359.102.3:2000correct |
Frequently asked questions
How much power does the Dovers 112 have?
The Dovers 112 delivers 1.5 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
