Demag AC80-2
Built: 2009-2014 · Series: Other models
More machines from model year 2009
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Demag – other mobile cranes registered as trucks: the AC (All Terrain Crane) series, lifting capacity in tonnes as the type name, 205 to 448 kW, kerb weight 32,750 to 96,000 kg
Demag was a German crane maker whose mobile-crane division belonged to Mannesmann and later to Terex, before the Japanese group Tadano took it over in 2019; in this register the vehicles appear as trucks because mobile cranes need a standard truck registration to travel on public roads. The AC range stands for "All Terrain Crane", with the attached number giving the maximum lifting capacity in tonnes – the AC 100 thus lifts up to 100 tonnes, the AC 700 up to 700 tonnes. Individual entries come from the Finnish vehicle register, where Demag mobile cranes are listed as "ajoneuvonosturi".
Read on 3 more paragraphs
The register lists 37 versions with six- to eight-cylinder engines from 6,370 to 15,930 cc, outputs from 205 to 448 kW, kerb weights from 32,750 to 96,000 kg and gross vehicle weights from 33,000 to 96,000 kg; width ranges from 2,500 to 3,000 mm.
Mobile cranes such as the AC range are used in high-rise and industrial construction, wind-turbine assembly and heavy-lift transport, where their own drive means they can reach the work site without a low-loader; Demag competed here with Liebherr and Grove.
When buying a used mobile crane, what matters above all is the operating hours on the hoist and telescopic boom, the condition of the hydraulic cylinders and hoses, and wear on the outriggers and axles from the high operating weight; servicing, inspection and spare parts today run through Tadano or specialist crane-service companies.
Sources: Kennwerte der Modelle Demag (weitere Modelle), Traficom (Finnland)
Technical data
Engine
| Power | 315 kWcorrect |
|---|---|
| Cylinders | 6correct |
| Displacement | 11,946 cm³correct |
Dimensions and weights
| Length | 13,500 mmcorrect |
|---|---|
| Width | 2,750 mmcorrect |
| Wheelbase | 7,650 mmcorrect |
| Unladen weight | 59,750 kgcorrect |
| Gross vehicle weight | 60,000 kgcorrect |
Drivetrain and chassis
| Wheels | 10correct |
|---|---|
| Top speed | 85 km/hcorrect |
Where this model stands
Power-to-weight ratio: 5.3 kW/t (315 kW / 59.8 t)
Stronger than 62% of the trucks over 7.5 t in the register — out of 25,424 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Demag AC80-2 have?
The Demag AC80-2 delivers 315 kW.
How much does the Demag AC80-2 weigh?
The unladen weight is 59,750 kg.
What is the gross vehicle weight of the Demag AC80-2?
60,000 kg.
What engine does the Demag AC80-2 have?
6 cylinders, 11,946 cm³ displacement.
How fast does the Demag AC80-2 go?
Top speed is 85 km/h.
What are the dimensions of the Demag AC80-2?
13,500 mm × 2,750 mm.
When was the Demag AC80-2 built?
Production years: 2009-2014.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 13 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
