DAF FT 95480 XF
Built: 1999-1999 · Series: FT
More machines from model year 1999
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
DAF FT – the tractor-unit designation: F range from the 2100 to the 95 XF with the T suffix for Trekker, DKS/DKTD and later DAF engines, 265 to 340 kW, for long-haul work with a semi-trailer
At DAF, the letter F denotes the classic angular cab family of the 1970s to 1990s, and the T suffix stands for Trekker – that is, the tractor unit for operation with a semi-trailer, as distinct from the A versions as a flatbed or box chassis. The model plates in the register range from the early FT 1600 and FT 2000 through the FT 2600/2800/3300 with DKA/DKS/DKX engines to the FT 95 and FT 95 XF of the 1990s with additional digits for cab and power; the letters D, H, K, S and U after the type number denote cab size and equipment.
Read on 3 more paragraphs
The register lists 105 versions here with engines from 265 to 340 kW from 6,099 to 14,016 cm³ displacement with 6 cylinders, kerb weights from 4,612 to 12,815 kg, gross weights from 11,990 to 26,500 kg, lengths from 5,050 to 8,550 mm and widths from 2,200 to 2,550 mm.
As tractor units, the FT types formed the backbone of DAF's long-haul programme for two decades, before the CF and XF ranges with a new type logic took over.
On these older DAF tractor units, what counts is frame and cab rust, the condition of the clutch and manual gearbox, the fifth wheel coupling and its wear, the cooling system and injection pump of the inline engines, and spare parts supply, which on the oldest model years increasingly runs only through specialists and vintage-DAF enthusiast clubs.
Sources: Kennwerte der Modelle DAF FT, DAF Trucks (Hersteller)
Technical data
Engine
| Cylinders | 6correct |
|---|---|
| Displacement | 12,580 cm³correct |
Dimensions and weights
| Length | 6,150 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 3,800 mmcorrect |
| Unladen weight | 6,990 kgcorrect |
| Gross vehicle weight | 20,500 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|---|
| Top speed | 90 km/hcorrect |
Frequently asked questions
How much does the DAF FT 95480 XF weigh?
The unladen weight is 6,990 kg.
What is the gross vehicle weight of the DAF FT 95480 XF?
20,500 kg.
What engine does the DAF FT 95480 XF have?
6 cylinders, 12,580 cm³ displacement.
How fast does the DAF FT 95480 XF go?
Top speed is 90 km/h.
What are the dimensions of the DAF FT 95480 XF?
6,150 mm × 2,550 mm.
When was the DAF FT 95480 XF built?
Production years: 1999.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 11 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
