Cummins PX-7 280 EV
Built: 2017-2026 · Series: PX-7
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Cummins PX-7 280 EV is a machine built by Cummins. Production: 2017-2026. The fuel is 7-15 ppm ultra low sulfur diesel. The rated output is 280 hp. Application: Vocational. The engine is turbocharged. It is a diesel engine. Rated output across the Cummins range ranges from 46 to 3,245 kW; the PX-7 280 EV sits at the bottom of that range with 280 kW. Its immediate neighbours are the ISV5.0 275 below it with 275 kW and the ISL9 300 above it with 285 kW. 517 Cummins models across 3 series are on record. The model is listed under Heavy-duty on-road engines. 21 verified figures from 3 sources are on file.
Technical data
Engine
| Engine code | BM8correct |
|---|---|
| Engine family | TCEXH0408BCFcorrect |
| Engine families | ECEXH0408BAP; GCEXH0408BAPcorrect |
| Fuel | 7-15 ppm ultra low sulfur dieselcorrect |
| Rated output | 280 hpcorrect |
| Rated speed | 2,400 rpmcorrect |
| Maximum torque | 660 ft·lbfcorrect |
| Speed at max. torque | 1,600 rpmcorrect |
| Displacement | 6.7 lcorrect |
| Operating cycle | dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
Origin and approval
| Version | BM8correct |
|---|---|
| Built from | 2014correct |
| Built to | 2016correct |
| Model year from | 2014correct |
| Model year to | 2026correct |
| Sales region | USA certificationcorrect |
Other data
| Anwendungsbereich | Vocationalcorrect |
|---|
Frequently asked questions
How much power does the Cummins PX-7 280 EV have?
The Cummins PX-7 280 EV delivers 280 kW.
When was the Cummins PX-7 280 EV built?
Production years: 2017-2026.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 21 individual figures for this model. They come from 3 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Other models in this series
PX-7 200
PX-7 200H
PX-7 220
PX-7 240
PX-7 250
PX-7 260
PX-7 260 EV
PX-7 260H
PX-7 280
PX-7 300
PX-7 300 EV
PX-7 325
Diesel engine in 3D section
Turn the model, look inside and click an assembly — each one is explained.
Teile zu diesem Motor (200)
Teilenummern des Herstellers aus der amtlichen EPA-Dokumentation. Ohne Preis und Verfügbarkeit — die kommen vom Lieferanten.
| Teilenummer | Bezeichnung | Hersteller |
|---|---|---|
| 4359192 | Aftertreatment Temperature Sensor | Cummins |
| 4359194 | Aftertreatment Temperature Sensor | Cummins |
| 4359195 | Aftertreatment Temperature Sensor | Cummins |
| 4359196 | Aftertreatment Temperature Sensor | Cummins |
| 4359197 | Aftertreatment Temperature Sensor | Cummins |
| 4359198 | Aftertreatment Temperature Sensor | Cummins |
| 4384561 | Aftertreatment Temperature Sensor | Cummins |
| 4384562 | Aftertreatment Temperature Sensor | Cummins |
| 4384563 | Aftertreatment Temperature Sensor | Cummins |
| 4384564 | Aftertreatment Temperature Sensor | Cummins |
| 4384565 | Aftertreatment Temperature Sensor | Cummins |
| 4384566 | Aftertreatment Temperature Sensor | Cummins |
| 4384567 | Aftertreatment Temperature Sensor | Cummins |
| 4384568 | Aftertreatment Temperature Sensor | Cummins |
| 4384569 | Aftertreatment Temperature Sensor | Cummins |
| 4384570 | Aftertreatment Temperature Sensor | Cummins |
| 4384571 | Aftertreatment Temperature Sensor | Cummins |
| 4384572 | Aftertreatment Temperature Sensor | Cummins |
| 4384573 | Aftertreatment Temperature Sensor | Cummins |
| 4384574 | Aftertreatment Temperature Sensor | Cummins |
| 4384575 | Aftertreatment Temperature Sensor | Cummins |
| 4384576 | Aftertreatment Temperature Sensor | Cummins |
| 4384577 | Aftertreatment Temperature Sensor | Cummins |
| 4384578 | Aftertreatment Temperature Sensor | Cummins |
| 4384579 | Aftertreatment Temperature Sensor | Cummins |
| 4384580 | Aftertreatment Temperature Sensor | Cummins |
| 5594132 | Aftertreatment Temperature Sensor | Cummins |
| 5654165 | Aftertreatment Temperature Sensor | Cummins |
| 5654166 | Aftertreatment Temperature Sensor | Cummins |
| 5654167 | Aftertreatment Temperature Sensor | Cummins |
| 5654168 | Aftertreatment Temperature Sensor | Cummins |
| 5654169 | Aftertreatment Temperature Sensor | Cummins |
| 5654170 | Aftertreatment Temperature Sensor | Cummins |
| 5654171 | Aftertreatment Temperature Sensor | Cummins |
| 5654172 | Aftertreatment Temperature Sensor | Cummins |
| 5654173 | Aftertreatment Temperature Sensor | Cummins |
| 5654174 | Aftertreatment Temperature Sensor | Cummins |
| 5654175 | Aftertreatment Temperature Sensor | Cummins |
| 5654176 | Aftertreatment Temperature Sensor | Cummins |
| 5654177 | Aftertreatment Temperature Sensor | Cummins |
| 5654178 | Aftertreatment Temperature Sensor | Cummins |
| 5654179 | Aftertreatment Temperature Sensor | Cummins |
| 5654180 | Aftertreatment Temperature Sensor | Cummins |
| 5654181 | Aftertreatment Temperature Sensor | Cummins |
| 5654182 | Aftertreatment Temperature Sensor | Cummins |
| 5654183 | Aftertreatment Temperature Sensor | Cummins |
| 5698544 | Aftertreatment Temperature Sensor | Cummins |
| 5698545 | Aftertreatment Temperature Sensor | Cummins |
| 5698546 | Aftertreatment Temperature Sensor | Cummins |
| 5698547 | Aftertreatment Temperature Sensor | Cummins |
| 5698548 | Aftertreatment Temperature Sensor | Cummins |
| 5698549 | Aftertreatment Temperature Sensor | Cummins |
| 5698550 | Aftertreatment Temperature Sensor | Cummins |
| 5698551 | Aftertreatment Temperature Sensor | Cummins |
| 5698552 | Aftertreatment Temperature Sensor | Cummins |
| 5698554 | Aftertreatment Temperature Sensor | Cummins |
| 5698557 | Aftertreatment Temperature Sensor | Cummins |
| 5698558 | Aftertreatment Temperature Sensor | Cummins |
| 5698560 | Aftertreatment Temperature Sensor | Cummins |
| 4354160 | Ammonia Slip Catalyst | Cummins |
| 2897333 | Charge Air Cooler Temperature | Cummins |
| 5698455 | Charge Air Cooler Temperature | Cummins |
| 5698454 | Compressor Inlet Combo Sensor;Compressor Inlet Temp/Pres Sensor (TBAP) | Cummins |
| 2897332 | Compressor Inlet Temperature | Cummins |
| 4954905 | Coolant Temperature Sensor;Coolant Temp Sensor;Coolant Temperature Sensor;Engine Out NOx Sensor 2;Coolant Temperature Sensor;Oil Temperature Sensor;Oil Temperature Sensor;Coolant Temperature Sensor;Coolant temp sensor | Cummins |
| 4354154 | Diesel Oxidation Catalyst | Cummins |
| 4388221 | Diesel Particulate Filter | Cummins |
| 2871960 | Diesel Particulate Filter Pressure | Cummins |
| 5492073 | Diesel Particulate Filter Pressure | Cummins |
| 5317072 | EGR Cooler | Cummins |
| 5341879 | EGR Cooler | Cummins |
| 5529387 | EGR Cooler | Cummins |
| 5566765 | EGR Cooler | Cummins |
| 4928594 | Exhaust Manifold Pressure;EGR Orifice Pressure Sensor;EGR pressure sensor | Cummins |
| 5397382 | EGR Valve | Cummins |
| 5397383 | EGR Valve | Cummins |
| 5586983 | EGR Valve | Cummins |
| 4384413 | Engine Control Module | Cummins |
| 5572390 | Engine Control Module | Cummins |
| 6393601 | Engine Control Module | Cummins |
| 5491326 | Engine Crankshaft;Engine Camshaft;Engine Camshaft;Engine Crankshaft;Engine Crankshaft;Engine Crankshaft;Engine Crankshaft service part;Engine Camshaft;Cam position sensor | Cummins |
| 5492132 | Engine Crankshaft;Engine Camshaft;Engine Camshaft;Engine Crankshaft;Engine Crankshaft service part;Engine speed sensor service part;Engine Crankshaft;Engine Crankshaft/cam position sensor;Engine Camshaft;Engine Crankshaft position sensor;Engine speed sensor service part;Engine Crankshaft/cam position sensor;Engine Crankshaft;Engine Crankshaft service part;Engine Camshaft | Cummins |
| 5295473 | Engine Out NOx Sensor | Cummins |
| 5302539 | Engine Out NOx Sensor | Cummins |
| 5306305 | Engine Out NOx Sensor | Cummins |
| 5306306 | Engine Out NOx Sensor | Cummins |
| 5340916 | Engine Out NOx Sensor | Cummins |
| 6313780 | Engine Out NOx Sensor | Cummins |
| 6376284 | Engine Out NOx Sensor | Cummins |
| 6376289 | Engine Out NOx Sensor | Cummins |
| 6395408 | Engine Out NOx Sensor | Cummins |
| 4327230 | Engine Crankshaft;Engine Crankshaft;Engine Cam;Engine Speed Sensor | Cummins |
| 2872858 | EGR Out Temperature Sensor;Intake Manifold Temp Sensor;EGR Out Temperature Sensor;EGR Out Temperature Sensor;Intake Manifold Temp Sensor;EGR temp sensor | Cummins |
| 4307166 | Exhaust Gas Recirculation Pressure | Cummins |
| 4384138 | Exhaust Gas Recirculation Pressure | Cummins |
| 6419882 | Exhaust Gas Recirculation Pressure | Cummins |
| 5491909 | Exhaust Pressure Sensor;EMP Sensor;Exhaust Manifold sensor | Cummins |
| 5398557 | Fuel Injection Pump | Cummins |
| 5256034 | Fuel Injector | Cummins |
| 5601422 | Fuel Injector | Cummins |
| 5601423 | Fuel Injector | Cummins |
| 5601424 | Fuel Injector | Cummins |
| 5640293 | Fuel Injector | Cummins |
| 5640294 | Fuel Injector | Cummins |
| 5640295 | Fuel Injector | Cummins |
| 4306993 | Fuel Pressure | Cummins |
| 5566375 | Fuel Pressure | Cummins |
| 4326861 | Tailpipe NOx Sensor | Cummins |
| 4326864 | Tailpipe NOx Sensor | Cummins |
| 4326868 | Tailpipe NOx Sensor | Cummins |
| 4326869 | Tailpipe NOx Sensor | Cummins |
| 4326872¿ | NOx Sensor Selective Catalytic Reduction | Cummins |
| 4326874 | Tailpipe NOx Sensor | Cummins |
| 5586982 | Part in service | Cummins |
| 5354480 | Turbocharger | Cummins |
| 5354482 | Turbocharger | Cummins |
| 5354493 | Turbocharger | Cummins |
| 5501345 | Turbocharger | Cummins |
| 5501347 | Turbocharger | Cummins |
| 5501358 | Turbocharger | Cummins |
| 5601425 | Turbocharger | Cummins |
| 5601435 | Turbocharger | Cummins |
| 5601436 | Turbocharger | Cummins |
| 5601547 | Turbocharger | Cummins |
| 5601548 | Turbocharger | Cummins |
| 5601549 | Turbocharger | Cummins |
| 5601550 | Turbocharger | Cummins |
| 5601560 | Turbocharger | Cummins |
| 5601561 | Turbocharger | Cummins |
| 5604930 | Turbocharger | Cummins |
| 5604931 | Turbocharger | Cummins |
| 5604932 | Turbocharger | Cummins |
| 5604933 | Turbocharger | Cummins |
| 5604934 | Turbocharger | Cummins |
| 5604935 | Turbocharger | Cummins |
| 5604936 | Turbocharger | Cummins |
| 5604937 | Turbocharger | Cummins |
| 5604938 | Turbocharger | Cummins |
| 5604939 | Turbocharger | Cummins |
| 5604940 | Turbocharger | Cummins |
| 5604941 | Turbocharger | Cummins |
| 5604942 | Turbocharger | Cummins |
| 5604943 | Turbocharger | Cummins |
| 5604944 | Turbocharger | Cummins |
| 5604945 | Turbocharger | Cummins |
| 5604946 | Turbocharger | Cummins |
| 5605010 | Turbocharger | Cummins |
| 5605011 | Turbocharger | Cummins |
| 5605012 | Turbocharger | Cummins |
| 5605013 | Turbocharger | Cummins |
| 5605014 | Turbocharger | Cummins |
| 5605015 | Turbocharger | Cummins |
| 5605016 | Turbocharger | Cummins |
| 5605017 | Turbocharger | Cummins |
| 5605018 | Turbocharger | Cummins |
| 5605019 | Turbocharger | Cummins |
| 5605020 | Turbocharger | Cummins |
| 5605021 | Turbocharger | Cummins |
| 5605022 | Turbocharger | Cummins |
| 5605023 | Turbocharger | Cummins |
| 5605024 | Turbocharger | Cummins |
| 5605025 | Turbocharger | Cummins |
| 5640273 | Turbocharger | Cummins |
| 5640274 | Turbocharger | Cummins |
| 5640275 | Turbocharger | Cummins |
| 5640276 | Turbocharger | Cummins |
| 5640287 | Turbocharger | Cummins |
| 5640288 | Turbocharger | Cummins |
| 5640296 | Turbocharger | Cummins |
| 5640307 | Turbocharger | Cummins |
| 5640308 | Turbocharger | Cummins |
| 5640398 | Turbocharger | Cummins |
| 5640400 | Turbocharger | Cummins |
| 5640411 | Turbocharger | Cummins |
| 5640417 | Turbocharger | Cummins |
| 5640419 | Turbocharger | Cummins |
| 5640430 | Turbocharger | Cummins |
| 5642527 | Turbocharger | Cummins |
| 5642528 | Turbocharger | Cummins |
| 6320581 | Turbocharger | Cummins |
| 6320762 | Turbocharger | Cummins |
| 6320827 | Turbocharger | Cummins |
| 6320851 | Turbocharger | Cummins |
| 6320876 | Turbocharger | Cummins |
| 6320883 | Turbocharger | Cummins |
| 6320902 | Turbocharger | Cummins |
| 6320907 | Turbocharger | Cummins |
| 6320913 | Turbocharger | Cummins |
| 6320933 | Turbocharger | Cummins |
| 6320941 | Turbocharger | Cummins |
| 6320948 | Turbocharger | Cummins |
| 6320964 | Turbocharger | Cummins |
| 6320967 | Turbocharger | Cummins |
| 6494320 | Turbocharger | Cummins |
| 6494410 | Turbocharger | Cummins |
| 6494726 | Turbocharger | Cummins |
| 6494888 | Turbocharger | Cummins |
| 6494910 | Turbocharger | Cummins |
| 6494946 | Turbocharger | Cummins |
| 6494972 | Turbocharger | Cummins |
Quelle: EPA HD Engines 2015–Present
Diese Teile anfragen
