CEG INPM32018503

Series: Other models

Source: https://www.kleinanzeigen.de/s-anzeige/elektromotor-mit-brem

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The CEG INPM32018503 is a three-phase induction motor. The rated output is 18.5 kW. The motor is two-pole, which at 50 Hz gives a synchronous speed of 3,000 rpm. The housing is frame size 160 L in foot-mounted form. The protection class is IP56 and IP66. The efficiency is 93.5 per cent at full load, 93.8 per cent at 75 per cent load and 93.5 per cent at half load. The motor weighs 140 kg. At full load it delivers 60.1 Nm. The motor is built in China. The figures come from the Australian MEPS register under standard AS/NZS 1359.5:2004; measured to AS/NZS 1359.102.3:2000. Rated output across the CEG range ranges from 0.75 to 160 kW; the INPM32018503 sits at the bottom of that range with 18.5 kW. Its immediate neighbours are the XNPM36015003 below it with 15 kW and the DCTM32022003 above it with 22 kW. 509 CEG models are on record. The model is listed under Electric motors. 24 verified figures from 1 source are on file.

Technical data

Engine

Rated output18.5 kWcorrect

Dimensions and weights

Weight140 kgcorrect

Electrical data

Number of poles2correct
Protection classIP56, IP66correct
Frame size160 L (foot)correct
Mounting (IEC 60034-7)B3, B5, B6, B7, B8, B9, B10, B14, B15, B20, B25, B34, B34, B35, V1, V2, V3, V4, V5, V6, V8, V9, V10, V14, V15, V16, V18, V19, V30, V31, V36correct
Efficiency at full load93.5 %correct
Efficiency at 75 % load93.8 %correct
Efficiency at half load93.5 %correct

Origin and approval

Country of manufactureChinacorrect
Standard appliedAS/NZS 1359.5:2004correct
Test methodAS/NZS 1359.102.3:2000correct

Frequently asked questions

How much power does the CEG INPM32018503 have?

The CEG INPM32018503 delivers 18.5 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
