Caterpillar 938H

Series: Caterpillar Wheel Loader

Source: https://www.profi.de/test/fahrbericht/radlader-caterpillar-9

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 938H, Caterpillar offers a model from the Caterpillar Wheel Loader series. The engine delivers 199.7 hp (134.2 kW), has 6 cylinders, with a displacement of 6,600.7 cm³. Torque is 840.6 Nm. Rated speed is 2,200 rpm. The unladen weight is 15,054.7 kg. The wheelbase measures 2,996.2 mm. Ground clearance is 381 mm. The tank holds 247.2 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. The pump delivers 294.9 l/min. The hydraulic tank holds 89 litres. The cooling system holds 36 litres. The electrical system runs on 24 V. The engine fitted is the 6,6 ACERT. Tyre size: 20,5R25. The Caterpillar Wheel Loader series covers 78 models. Rated output within it ranges from 42.6 to 1,598.9 hp; the 938H sits at the bottom of that range with 199.7 hp. Its immediate neighbours are the 950G below it with 182.5 hp and the 962G above it with 202.8 hp. 1091 Caterpillar models across 47 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine model6.6 ACERTcorrect
Power199.7 hp (134.2 kW)correct
Rated speed2,200 rpmcorrect
Torque840.6correct
Cylinders6correct
Displacement6,600.7 cm³correct
Coolant capacity36 lcorrect

Dimensions and weights

Length7,187.2correct
Wheelbase2,996.2correct
Ground clearance381correct
Unladen weight15,054.7 kgcorrect

Drivetrain and chassis

Gearbox typepowershift transmissioncorrect
Forward gears4correct
Reverse gears3correct
Tyre size20.5R25correct
System voltage24 Vcorrect

Working data

Pump flow294.9 l/mincorrect
Hydraulic oil capacity89 lcorrect
Fuel tank capacity247.2 lcorrect

Other data

Height3,352.8correct

Where this model stands

Power-to-weight ratio: 8.9 kW/t (134 kW / 15.1 t)

Stronger than 68% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Caterpillar 938H have?

The Caterpillar 938H delivers 200 hp.

How much does the Caterpillar 938H weigh?

The unladen weight is 15,055 kg.

What engine does the Caterpillar 938H have?

6 cylinders, 6,601 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
