Caterpillar 256C

Series: Caterpillar Skid Steer Loader

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Caterpillar 256C is a model in the Caterpillar Skid Steer Loader series. The engine delivers 86.2 hp (61.1 kW), has 4 cylinders, with a displacement of 3,293.8 cm³. Rated speed is 2,500 rpm. The wheelbase measures 1,240.5 mm. Ground clearance is 223.8 mm. Top speed is 12.4 km/h. The tank holds 98.4 litres. The pump delivers 83.3 l/min. The hydraulic tank holds 56.8 litres. Working pressure is 229.9 bar. The cooling system holds 14 litres. The engine fitted is the 3044C DIT. The Caterpillar Skid Steer Loader series covers 35 models. Rated output within it ranges from 51.7 to 95.3 hp; the 256C sits in the upper part of that range with 86.2 hp. Its immediate neighbours are the 262C below it with 85.2 hp and the 272C above it with 95.3 hp. 1091 Caterpillar models across 47 series are on record. The model is listed under Wheel loaders. 15 verified figures from 1 source are on file.

Technical data

Engine

Engine model3044C DITcorrect
Power86.2 hp (61.1 kW)correct
Rated speed2,500 rpmcorrect
Cylinders4correct
Displacement3,293.8 cm³correct
Coolant capacity14 lcorrect

Dimensions and weights

Wheelbase1,240.5correct
Ground clearance223.8correct

Drivetrain and chassis

Top speed12.4 km/hcorrect

Working data

Pump flow83.3 l/mincorrect
Hydraulic oil capacity56.8 lcorrect
Hydraulic pressure229.9correct
Fuel tank capacity98.4 lcorrect

Other data

Height2,081.8correct

Frequently asked questions

How much power does the Caterpillar 256C have?

The Caterpillar 256C delivers 86.2 hp.

What engine does the Caterpillar 256C have?

4 cylinders, 3,294 cm³ displacement.

How fast does the Caterpillar 256C go?

Top speed is 12.4 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
