Caterpillar 216B Series 2

Series: Caterpillar Skid Steer Loader

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 216B Series 2, Caterpillar offers a model from the Caterpillar Skid Steer Loader series. The engine delivers 51.7 hp (36.5 kW), with a displacement of 2,195.9 cm³. The unladen weight is 2,544.2 kg. The wheelbase measures 990.6 mm. Ground clearance is 203.2 mm. Top speed is 11.3 km/h. The tank holds 58.3 litres. The pump delivers 59.1 l/min. The hydraulic tank holds 54.9 litres. Working pressure is 229.9 bar. The cooling system holds 9.8 litres. The engine fitted is the Cat C2,2. The Caterpillar Skid Steer Loader series covers 35 models. Rated output within it ranges from 51.7 to 95.3 hp; the 216B Series 2 sits at the bottom of that range with 51.7 hp. Its immediate neighbours are the 216B above it with 52.7 hp. 1091 Caterpillar models across 47 series are on record. The model is listed under Wheel loaders. 14 verified figures from 1 source are on file.

Technical data

Engine

Engine modelCat C2.2correct
Power51.7 hp (36.5 kW)correct
Displacement2,195.9 cm³correct
Coolant capacity9.8 lcorrect

Dimensions and weights

Wheelbase990.6correct
Ground clearance203.2correct
Unladen weight2,544.2 kgcorrect

Drivetrain and chassis

Top speed11.3 km/hcorrect

Working data

Pump flow59.1 l/mincorrect
Hydraulic oil capacity54.9 lcorrect
Hydraulic pressure229.9correct
Fuel tank capacity58.3 lcorrect

Other data

Height1,956.8correct

Where this model stands

Power-to-weight ratio: 14.3 kW/t (36 kW / 2.5 t)

Stronger than 25% of the skid steer loaders in the register — out of 296 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Caterpillar 216B Series 2 have?

The Caterpillar 216B Series 2 delivers 51.7 hp.

How much does the Caterpillar 216B Series 2 weigh?

The unladen weight is 2,544 kg.

What engine does the Caterpillar 216B Series 2 have?

2,196 cm³ displacement.

How fast does the Caterpillar 216B Series 2 go?

Top speed is 11.3 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
