Caterpillar 252B Series 2

Series: Caterpillar Skid Steer Loader

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Caterpillar Skid Steer Loader series from Caterpillar includes the 252B Series 2. The engine delivers 76 hp (52.2 kW), has 4 cylinders, with a displacement of 3,293.8 cm³. Rated speed is 2,600 rpm. The unladen weight is 3,565.7 kg. The wheelbase measures 1,225.3 mm. Ground clearance is 195.6 mm. Top speed is 11.3 km/h. The tank holds 90.1 litres. The pump delivers 83.3 l/min. The hydraulic tank holds 53 litres. Working pressure is 229.9 bar. The cooling system holds 9.8 litres. The electrical system runs on 12 V. The engine fitted is the Cat C3,4 DIT. The Caterpillar Skid Steer Loader series covers 35 models. Rated output within it ranges from 51.7 to 95.3 hp; the 252B Series 2 sits in the middle of that range with 76 hp. Its immediate neighbours are the 236D below it with 75.3 hp and the 246 above it with 81.1 hp. 1091 Caterpillar models across 47 series are on record. The model is listed under Wheel loaders. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine modelCat C3.4 DITcorrect
Power76 hp (52.2 kW)correct
Rated speed2,600 rpmcorrect
Cylinders4correct
Displacement3,293.8 cm³correct
Coolant capacity9.8 lcorrect

Dimensions and weights

Wheelbase1,225.3correct
Ground clearance195.6correct
Unladen weight3,565.7 kgcorrect

Drivetrain and chassis

Top speed11.3 km/hcorrect
System voltage12 Vcorrect

Working data

Pump flow83.3 l/mincorrect
Hydraulic oil capacity53 lcorrect
Hydraulic pressure229.9correct
Fuel tank capacity90.1 lcorrect

Other data

Height2,097correct

Where this model stands

Power-to-weight ratio: 14.6 kW/t (52 kW / 3.6 t)

Stronger than 58% of the skid steer loaders in the register — out of 296 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Caterpillar 252B Series 2 have?

The Caterpillar 252B Series 2 delivers 76 hp.

How much does the Caterpillar 252B Series 2 weigh?

The unladen weight is 3,566 kg.

What engine does the Caterpillar 252B Series 2 have?

4 cylinders, 3,294 cm³ displacement.

How fast does the Caterpillar 252B Series 2 go?

Top speed is 11.3 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
