Case 686G XR

Series: Case Telescopic Forklift

Source: https://www.schaeffer.de/en/products/19/telescopic-wheel-loa

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Case 686G XR is a model in the Case Telescopic Forklift series. The engine delivers 111.5 hp (73.8 kW), has 4 cylinders, with a displacement of 3,916.5 cm³. Torque is 397.3 Nm. Rated speed is 2,500 rpm. The unladen weight is 8,890.4 kg. The wheelbase measures 3,002.3 mm. The tank holds 132.5 litres. The gearbox has 3 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,500 rpm. The pump delivers 128.7 l/min. The hydraulic tank holds 151.4 litres. The electrical system runs on 12 V. The engine fitted is the 4T-390. Tyre size: 13,00x24 12PR L2/G2. The Case Telescopic Forklift series covers 13 models. Rated output within it ranges from 81.1 to 121.7 hp; the 686G XR sits in the upper part of that range with 111.5 hp. Its immediate neighbours are the TX742 below it with 102.4 hp and the TC1055 above it with 121.7 hp. 620 Case models across 22 series are on record. The model is listed under Telehandlers. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine model4T-390correct
Power111.5 hp (73.8 kW)correct
Rated speed2,500 rpmcorrect
Torque397.3correct
Speed at max. torque1,500 rpmcorrect
Cylinders4correct
Displacement3,916.5 cm³correct
Aspirationturbochargedcorrect

Dimensions and weights

Height2,400 mmcorrect
Wheelbase3,002.3correct
Unladen weight8,890.4 kgcorrect

Drivetrain and chassis

Gearbox typepowershift transmissioncorrect
Forward gears3correct
Reverse gears3correct
Tyre size13.00x24 12PR L2/G2correct
System voltage12 Vcorrect

Working data

Lift height12,800 mmcorrect
Pump flow128.7 l/mincorrect
Hydraulic oil capacity151.4 lcorrect
Fuel tank capacity132.5 lcorrect

Where this model stands

Power-to-weight ratio: 8.3 kW/t (74 kW / 8.9 t)

Stronger than 31% of the telehandlers in the register — out of 661 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Case 686G XR have?

The Case 686G XR delivers 112 hp.

How much does the Case 686G XR weigh?

The unladen weight is 8,890 kg.

What engine does the Case 686G XR have?

4 cylinders, 3,916 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
