Branson F47Rn
Built: 2019-2020 · Series: Other models
More machines from model year 2019
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Built in 2019-2020, the Branson F47Rn is a tractor from Branson. Power comes from a three-cylinder engine; from 1.7 litres it draws 33.5 kW.
It measures 3.43 m in length and 1.48 m in width. Unladen weight is 1,471 kg.
Within the range, rated power spans from 17.9 to 44.1 kW; with 33.5 kW, the F47Rn sits in the upper third. Directly alongside are the 4720i with 31.3 kW below and the 5025C with 34 kW above.
Branson – other models: South Korean compact and mid-size tractors outside the named ranges, from 2400 to 6530, 17.9 to 44.1 kW, A2300 and B3.3 diesel engines
This page gathers the Branson tractors that the register could not assign to a named range – compact and mid-size models of the 2400, 2800, 3100, 3510, 4720, 5025, 5530 and 6225 series, plus older types with F and N designations. Branson is a South Korean manufacturer whose tractors are built primarily for the North American market and sold there through its own dealer network. For engines the register gives both general entries such as diesel and specific type designations such as A2300N2, A2300T2-ATC and B3.3 NA for three- and four-cylinder units.
Read on 3 more paragraphs
The register lists 47 versions here with 17.9 to 44.1 kW from three- and four-cylinder engines of 1,101 to 3,261 cm³, unladen weights of 843 to 2,665 kg, gross vehicle weights of 1,600 to 3,230 kg, lift capacities of 971 to 1,250 kg, lengths of 2,668 to 3,660 mm, widths of 1,290 to 1,814 mm and PTO outputs of 22 to 38 hp at a rated speed of 2,600 rpm.
Branson positions itself in the compact and mid-size segment against established brands such as Kubota, Kioti and Mahindra, with a focus on yard and grassland work, municipal use, and hobby and part-time farming in the United States and Canada.
When buying used, the condition of the hydrostatic or gear transmission, the tightness of hydraulic connections at the front hitch and PTO, rust on sheet-metal parts and the exhaust system, and recorded hours are decisive; since Branson has little presence in Europe, parts supply outside North America depends heavily on the relevant importer.
Technical data
Engine
| Power | 33.5 kWcorrect |
|---|---|
| Cylinders | 3correct |
| Displacement | 1,715 cm³correct |
Dimensions and weights
| Length | 3,429 mmcorrect |
|---|---|
| Width | 1,477 mmcorrect |
| Unladen weight | 1,471 kgcorrect |
| Gross vehicle weight | 2,500 kgcorrect |
Where this model stands
Power-to-weight ratio: 22.8 kW/t (34 kW / 1.5 t)
Power class: Universal (40–100 hp)
Stronger than 30% of the tractors in the register — out of 15,260 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Branson F47Rn have?
The Branson F47Rn delivers 33.5 kW.
How much does the Branson F47Rn weigh?
The unladen weight is 1,471 kg.
What is the gross vehicle weight of the Branson F47Rn?
2,500 kg.
What engine does the Branson F47Rn have?
3 cylinders, 1,715 cm³ displacement.
What are the dimensions of the Branson F47Rn?
3,429 mm × 1,477 mm.
When was the Branson F47Rn built?
Production years: 2019-2020.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
