Branson 4720h 4WD
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Branson 4720h is a tractor from the Branson 4WD Tractor series. Power comes from a four-cylinder engine; from 2.3 litres it draws 48 hp (35 kW). Rated power arrives at 2,600 rpm — the engine pulls from low down rather than needing to be revved.
Unladen, it tips the scales at 1,867 kg.
Within the range, rated power spans from 29.4 to 65.9 hp; with 47.7 hp, the 4720h sits in the upper third. Directly alongside are the 4720i with 42.6 hp below and the 5530C with 55.8 hp above.
Technical data
Engine
| Engine model | A2300N2correct |
|---|---|
| Power | 47.7 hp (35 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 2,287.6 cm³correct |
Dimensions and weights
| Unladen weight | 1,867 kgcorrect |
|---|
Drivetrain and chassis
| Gearbox type | synchromesh gearboxcorrect |
|---|---|
| Forward gears | 12correct |
| Reverse gears | 12correct |
| Tyre size | front: 8-18, rear:12.4-28correct |
| System voltage | 12 Vcorrect |
Working data
| Pump flow | 31.8 l/mincorrect |
|---|---|
| Fuel tank capacity | 37.1 lcorrect |
Other data
| Height | 2,465.8correct |
|---|
Where this model stands
Power-to-weight ratio: 18.7 kW/t (35 kW / 1.9 t)
Power class: Universal (40–100 hp)
Stronger than 33% of the tractors in the register — out of 15,240 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Branson 4720h have?
The Branson 4720h delivers 47.7 hp.
How much does the Branson 4720h weigh?
The unladen weight is 1,867 kg.
What engine does the Branson 4720h have?
4 cylinders, 2,288 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
