Bolinder Munktell VHK85

Series: Bolinder Munktell Motor Grader

Source: https://www.nyongesasande.com/bolinder-munktell-farm-tractor

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Bolinder Munktell VHK85 belongs to the Bolinder Munktell Motor Grader series. The engine delivers 86.2 hp, with a displacement of 6,730.2 cm³. The unladen weight is 13,650 kg. The wheelbase measures 5,501.6 mm. Ground clearance is 640.1 mm. The electrical system runs on 24 V. The engine fitted is the D67A. Tyre size: 13,00-24 12ply. The Bolinder Munktell Motor Grader series covers 4 models. Rated output within it ranges from 76 to 111.5 hp; the VHK85 sits in the lower part of that range with 86.2 hp. Its immediate neighbours are the VHK55 below it with 76 hp and the VHK100 above it with 101.4 hp. 46 Bolinder Munktell models across 4 series are on record.

Bolinder-Munktell Motor Grader – the VHK55 to VHK115 range from Eskilstuna: six-cylinder D67 diesel, around 6.7 litres displacement, unladen weights from 11.25 to 13.65 tonnes

Bolinder-Munktell was formed in 1932 from the merger of the machine works J. & C. G. Bolinder and Munktells in Eskilstuna and built diesel engines and construction machinery alongside tractors; in 1950 Volvo took over the plant, which traded as Volvo BM and built Swedish construction machinery into the 1990s. This page gathers the brand's motor graders, the types VHK55, VHK85, VHK100 and VHK115. They were powered by the in-house six-cylinder D67 or D67A diesel of just over 6.7 litres.

Read on 3 more paragraphs

The register lists here 4 versions with displacements from 6,720.3 to 6,730.2 cm³, unladen weights from 11,250 to 13,650 kg and lengths from 7,522.5 to 7,751.1 mm.

Graders of this class served road building and maintenance on gravel and rural roads, levelling construction sites and winter road maintenance in the Nordic countries, where frost and snow clearance place heavy demands on drivetrain and blade. Volvo BM was, alongside Åkerman, one of the leading construction-machinery brands of Scandinavia before the grader programme was fully absorbed into Volvo Construction Equipment, and the Eskilstuna graders became sought-after pieces of Swedish construction-machinery history.

On these grader classics, the condition of the circle and blade-adjustment mechanism, the tightness of the hydraulic cylinders for blade and steering, cracks in frame and axle suspension, and the general condition of the engine, radiator and injection pump of the D67 diesel all count.

Sources: Kennwerte der Modelle Bolinder Munktell Motor Grader

Technical data

Engine

Engine model	D67Acorrect
Power	86.2 hpcorrect
Displacement	6,730.2 cm³correct

Dimensions and weights

Length	7,522.5 mmcorrect
Wheelbase	5,501.6 mmcorrect
Ground clearance	640.1correct
Unladen weight	13,650 kgcorrect

Drivetrain and chassis

Gearbox type	constant-mesh gearboxcorrect
Tyre size	13.00-24 12plycorrect

Other data

System voltage	24 Vcorrect

Where this model stands

Power-to-weight ratio: 4.6 kW/t (63 kW / 13.7 t)

Stronger than 2% of the motor graders in the register — out of 186 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Bolinder Munktell VHK85 have?

The Bolinder Munktell VHK85 delivers 86.2 hp.

How much does the Bolinder Munktell VHK85 weigh?

The unladen weight is 13,650 kg.

What engine does the Bolinder Munktell VHK85 have?

6,730 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
