EMMINGHAUS PIONIER 1201
Built: 1993–1995 · Series: Other models
More machines from model year 1993
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Emminghaus – other models: the collective page of trailers outside the named ranges, from the Pionier 1201 to the Pionier HDB 120-6-22, 1,180 to 1,640 kg unladen weight, 1,200 to 1,800 kg gross weight
This page gathers the trailers of the Emminghaus brand that the register does not assign to its own range. Almost all versions carry the Pionier name suffix, supplemented by numeric codes such as 120425, 120525 or 120622 and the HDB 120-6-22 variant; the standalone designation 120622 without the suffix corresponds to the same numeric scheme as the matching Pionier version.
Read on 3 more paragraphs
The register lists here 7 versions with unladen weights from 1,180 to 1,640 kg and gross weights from 1,200 to 1,800 kg at widths from 1,590 to 1,650 mm; for one model a length of 7,400 mm is additionally recorded.
With a gross weight of up to 1,800 kg at a comparatively narrow width of around 1.6 m, the Pionier versions sit in the segment of narrow, sturdy utility trailers of class O2, designed for transport on narrower tracks or in tight yard situations. The close spacing between unladen weight and gross weight shows a construction built for sturdiness rather than weight saving.
Buying used, check the condition of the frame and its corrosion protection, the function of the axle and overrun brake, the condition of the side panels and load floor, and the tyres and lighting. Parts for axles, brakes and lighting run through the general trailer and commercial-vehicle parts trade; on the narrower frame it is also worth checking the drawbar for straightness after possible collisions.
Sources: SpecCodex register, model data: Emminghaus (weitere Modelle)
Technical data
Dimensions and weights
| Width | 1,600 mmcorrect |
|---|---|
| Unladen weight | 1,180 kgcorrect |
| Gross vehicle weight | 1,250 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the EMMINGHAUS PIONIER 1201 weigh?
The unladen weight is 1,180 kg.
What is the gross vehicle weight of the EMMINGHAUS PIONIER 1201?
1,250 kg.
Up to what speed is the EMMINGHAUS PIONIER 1201 approved?
Approved up to 100 km/h.
When was the EMMINGHAUS PIONIER 1201 built?
Production years: 1993–1995.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 6 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
