Allis Gleaner Corporation DT-225 B

Built: 2009–2010 · Series: DT/B - Baureihe

More machines from model year 2009

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Allis Gleaner Corporation DT-225 B belongs to the DT/B series. Production: 2009–2010. The engine delivers 265 hp (194.9 kW), has 6 cylinders, with a displacement of 8,419 cm³. Torque is 1,222 Nm. Rated speed is 2,200 rpm. The machine is 5,479 mm long, 2,014 mm wide and 3,581 mm high. The unladen weight is 11,720 kg. The wheelbase measures 3,105 mm. Ground clearance is 470 mm. Top speed is 40 km/h. Transmission: continuously variable. The engine is water-cooled. Tyres: front 480/70 R 34 AS, rear 520/85 R 46 AS. The fuel is diesel. The bore measures 111 mm. The stroke is 145 mm. The compression ratio is 16.7:1. Maximum torque is reached at 1,400 rpm. The DT/B - Baureihe series covers 4 models. Rated output within it ranges from 240 to 320 hp; the DT-225 B sits in the lower part of that range with 265 hp. Its immediate neighbours are the DT-205 B below it with 240 hp and the DT-250 B above it with 290 hp. 40 Allis Gleaner Corporation models across 9 series are on record.

Allis-Gleaner Corporation (AGCO) DT/B series – DT-205 B to DT-275 B: the top models of the big standard tractors, 176 to 235 kW, 11.7 t

The DT/B series formed the top of the big standard tractors at the Allis-Gleaner Corporation (AGCO): the DT-205 B, DT-225 B, DT-250 B and DT-275 B were the most powerful versions in the DT family. The Allis-Gleaner Corporation emerged in 1990 from the management buyout of the farm-equipment division of Klöckner-Humboldt-Deutz, which had previously traded as Deutz-Allis, becoming the foundation of today's AGCO group.

Read on 3 more paragraphs

The register lists here 4 versions with 176.5 to 235.4 kW from six-cylinders of 8,419 cm³ displacement, torque from 1,126 to 1,432 Nm at 2,200 rpm, an unladen weight of 11,720 kg, lengths from 5,479 to 5,670 mm, a width of 2,014 mm and heights from 3,380 to 3,581 mm – all with diesel engines.

With unladen weights approaching twelve tonnes and torque above 1,400 Nm, the DT/B series marked the top end of conventional, non-articulated standard tractors and targeted large operations with correspondingly heavy primary-tillage equipment such as chisel ploughs and heavy disc harrows.

Used, the DT/B series calls for checking the turbocharger and charge-air cooling under sustained high output, transmission and axle drive at the high weights, hydraulic pump and cooling system, and frame and implement mounts; brakes and tyres should also be checked for the weight class. Spare parts run through the AGCO organisation.

Sources: SpecCodex register, model data: Allis-Gleaner Corporation DT/B-Baureihe, AGCO Corporation

Technical data

Engine

Fuel	dieselcorrect
Power	265 hp (194.9 kW)correct
Rated speed	2,200 rpmcorrect
Torque	1,222 Nmcorrect
Speed at max. torque	1,400 rpmcorrect
Cylinders	6correct
Displacement	8,419 cm³correct
Bore	111 mmcorrect
Stroke	145 mmcorrect
Compression ratio	16.7correct
Cooling	water-cooledcorrect

Dimensions and weights

Length	5,479 mmcorrect
Width	2,014 mmcorrect
Height	3,581 mmcorrect
Wheelbase	3,105 mmcorrect
Ground clearance	470 mmcorrect
Unladen weight	11,720 kgcorrect

Drivetrain and chassis

Drive	four-wheel drivecorrect
Gearbox	continuously variablecorrect
Front tyres	480/70 R 34 AScorrect
Rear tyres	520/85 R 46 AScorrect
Top speed	40 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 16.6 kW/t (195 kW / 11.7 t)

Power class: Heavy (> 180 hp)

Stronger than 96% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Allis Gleaner Corporation DT-225 B have?

The Allis Gleaner Corporation DT-225 B delivers 265 hp.

How much does the Allis Gleaner Corporation DT-225 B weigh?

The unladen weight is 11,720 kg.

What engine does the Allis Gleaner Corporation DT-225 B have?

6 cylinders, 8,419 cm³ displacement, Diesel.

How fast does the Allis Gleaner Corporation DT-225 B go?

Top speed is 40 km/h.

What are the dimensions of the Allis Gleaner Corporation DT-225 B?

5,479 mm × 2,014 mm × 3,581 mm.

When was the Allis Gleaner Corporation DT-225 B built?

Production years: 2009–2010.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
