AGCO GT45
Built: 2004-2004 · Series: Other models
Successor: GT45A →
More machines from model year 2004
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The AGCO GT45 rolled off the line in 2004 as a tractor. The three-cylinder engine produces 34 kW.
Power is transmitted through a Synchro Shuttle gearbox.
It runs on diesel; the engine is water-cooled. It was replaced by the AGCO GT45A. Within the range, rated power spans from 16.8 to 216 kW; with 34 kW, the GT45 sits in the lower third. Directly alongside are the GT45A with 33 kW below and the ST47a with 34.3 kW above.
Technical data
Engine
| Engine make | SDFcorrect |
|---|---|
| Engine model | 1000.3W2correct |
| Fuel | dieselcorrect |
| Power | 45 hp (34 kW)correct |
| Cylinders | 3correct |
| Displacement | 183 CIDcorrect |
| Bore | 4.13 in (104,9 mm)correct |
| Stroke | 4.55 in (115,6 mm)correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 145.7 in (3700,8 mm)correct |
|---|---|
| Width | 70.4 in (1788,2 mm)correct |
| Height | 103.6correct |
| Wheelbase | 82.9 in (2WD); 80.9 in (MFWD)correct |
| Turning circle | 10 ft (2WD); 12 ft (MFWD)correct |
| Unladen weight | 5, 335 lbs (2WD); 5, 820 lbs (MFWD)correct |
Drivetrain and chassis
| Drive | rear-wheel driveWD/MFWDcorrect |
|---|---|
| Gearbox | Synchro Shuttlecorrect |
| Forward gears | 16correct |
| Reverse gears | 8correct |
| Clutch | drycorrect |
Working data
| Lifting capacity | 6,392 lbs (2899,4 kg)correct |
|---|---|
| Fuel tank capacity | 23.8 galcorrect |
Origin and approval
| Plant | Italycorrect |
|---|
Other data
| Linkage category | Cat IIcorrect |
|---|---|
| PTO speed | 540/1000correct |
| Successor | AGCO GT45Acorrect |
Frequently asked questions
How much power does the AGCO GT45 have?
The AGCO GT45 delivers 45 hp.
What engine does the AGCO GT45 have?
3 cylinders, Diesel.
When was the AGCO GT45 built?
Production years: 2004.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
