Yale GLP20SVX

Series: Yale Treibgasstapler

Source: https://canvas.yale.edu/about

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The GLP20SVX from Yale is part of the Yale Treibgasstapler series. The engine delivers 40 hp, has 4 cylinders, with a displacement of 1,999 cm³. Torque is 111 Nm. Rated speed is 2,600 rpm. The machine is 1,070 mm wide and 2,180 mm high. The unladen weight is 3,294 kg. The wheelbase measures 1,390 mm. Top speed is 21 km/h. Lifting capacity is 2,000 kg. Lift height is 6,550 mm. The mast is a Triplex type. The Yale Treibgasstapler series covers 40 models. Lifting capacity within it ranges from 1,600 to 7,000 kg; the GLP20SVX sits at the bottom of that range with 2,000 kg. Its immediate neighbours are the GLP16VX below it with 1,600 kg and the GLP25VXV2170 above it with 2,490 kg. 380 Yale models across 18 series are on record. The model is listed under LPG forklifts. 13 verified figures from 2 sources are on file.

Technical data

Engine

Power40 hpcorrect
Rated speed2,600 rpmcorrect
Torque111 Nmcorrect
Cylinders4correct
Displacement1,999 cm³correct

Dimensions and weights

Width1,070 mmcorrect
Height2,180 mmcorrect
Wheelbase1,390 mmcorrect
Unladen weight3,294 kgcorrect

Drivetrain and chassis

Top speed21 km/hcorrect

Working data

Lifting capacity2,000 kgcorrect
Lift height6,550 mmcorrect
Mast typetriplexcorrect

Frequently asked questions

How much power does the Yale GLP20SVX have?

The Yale GLP20SVX delivers 40 hp.

How much does the Yale GLP20SVX weigh?

The unladen weight is 3,294 kg.

What engine does the Yale GLP20SVX have?

4 cylinders, 1,999 cm³ displacement.

How fast does the Yale GLP20SVX go?

Top speed is 21 km/h.

What is the load capacity of the Yale GLP20SVX?

Load capacity is 2,000 kg, lift height 6,550 mm.

What are the dimensions of the Yale GLP20SVX?

1,070 mm × 2,180 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
