Wilo 4210739
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Wilo – other models: the collective page of pump motors outside the named ranges, exclusively two-pole, MHI motors and the IL/DL/MVI ranges, 0.75 to 2.2 kW, foot and flange versions
Wilo, founded in 1872 in Dortmund, is one of the large European makers of pumps and pump motors. This page gathers the motors the Australian energy-efficiency register could not assign to a named range, including pure spare-part numbers such as 3514167 and short codes such as MVI, IL, DL and IPL, referring to Wilo's pump ranges (vertical multistage and inline centrifugal pumps). Some motors are recorded in the register explicitly as "MHI Motors … by Wilo France S.A.S." and thus come from Wilo's French subsidiary.
Read on 3 more paragraphs
The register lists here 20 versions with 0.75 to 2.2 kW, uniformly two-pole, full-load efficiencies from 81.8 to 87.5% and at 75% load from 82.6 to 88%. The build form ranges from the flange version frame size 100 to the foot versions 80M and 90M, protection is IP54 and IP55. Testing followed the 2019 GEMS determination and AS/NZS 1359.5:2004, with test methods A, B and 2-1-1B; eleven of the 20 motors carry a documented High Efficiency classification, one of them at the 2005 level.
As pump motors, all 20 versions are two-pole, matched to the typical centrifugal-pump speed of around 2,900 rpm, and cover the lower power segment of heating, cooling and circulation pumps, closely tied to Wilo's own pump range.
When buying used, the condition of the mechanical seal and shaft seal, a checked insulation resistance of the winding, bearing and fan-cover condition, and a legible nameplate with build form, output and voltage rating matter; on the flange motors, the condition of the centring to the pump housing should also be checked. Spares run through the Wilo service network.
Sources: Kennwerte der Modelle Wilo (weitere Modelle, MEPS-Registrierungen), Wilo (Hersteller)
Technical data
Engine
| Engine family | MHI Motors (0, 75/80) by Wilo France S.A.S.correct |
|---|---|
| Engine families | MHI Motors (0, 75/80) by Wilo France S.A.S.correct |
| Rated output | 0.75 kWcorrect |
Electrical data
| Rated voltage | 230/400 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP54correct |
| Frame size | 80 M (foot)correct |
| Mounting (IEC 60034-7) | B35correct |
| Efficiency at full load | 81.8 %correct |
| Efficiency at 75 % load | 82.6 %correct |
| Efficiency at half load | 81.1 %correct |
Origin and approval
| Country of manufacture | Francecorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the Wilo 4210739 have?
The Wilo 4210739 delivers 0.8 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
