WEG KTE61 PHEM
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
WEG – other models: the collective page of three-phase motors outside the named ranges from the Australian GEMS/MEPS register, 0.75 to 160 kW, 2- to 8-pole, IEC frame sizes 80 to 355, efficiencies up to 96.3%
This page gathers the WEG three-phase motors the register could not assign to a named range, recording them individually from the Australian GEMS/MEPS registration database for electric motors. WEG was founded in 1961 in Jaraguá do Sul, Brazil, the name taken from the initials of its three founders, and the manufacturer is today one of the world's largest builders of electric motors. The models recorded here come almost entirely from Brazilian production. The type plates follow noticeably different schemes: codes such as 160M appear to name the IEC frame size directly, while ranges such as K10A or K11 seem more likely to mark a product family with protection- and ignition-safety variants (ALE, EXNE, EXDE, STDE) – this cannot be inferred from the codes alone with certainty.
Read on 3 more paragraphs
The register lists here 375 versions from 0.75 to 160 kW, 2- to 8-pole, with efficiencies from 76 to 96.3% at full load and 73.5 to 96.3% at 75% load, protection classes from IP55 to IP66 and frame sizes from 80 to 355 (IEC). For 106 of the models the register shows the classification "2005 High Efficiency Level", roughly equivalent to class IE2; the majority carry no such classification.
Alongside ABB and Siemens, WEG is one of the volume manufacturers of industrial three-phase motors, and this collective page covers the broad middle ground of standard motors not assigned to any separately maintained range – from small units for pumps and fans to motors for compressors and conveying plant.
For used WEG standard motors the rating plate comes first: frame size, pole count, efficiency class and protection class must match the intended application. Beyond that comes an insulation resistance test of the winding, the condition of the bearings (running noise, bearing play, re-greasing ability on larger frames), free running of the shaft, the condition of the fan and fan cowl, and – for planned inverter operation – whether the winding insulation and bearings are rated for operation on a variable-frequency drive.
Sources: Kennwerte der Modelle WEG (weitere Modelle), WEG (Hersteller)
Technical data
Engine
| Rated output | 132 kWcorrect |
|---|
Dimensions and weights
| Weight | 900 kgcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | 65correct |
| Frame size | 315 S (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B35, B34, B14, B6, B7, B8, V5, V6, V1, V3, V15, V36, V18, V19correct |
| Efficiency at full load | 96 %correct |
| Efficiency at 75 % load | 95.5 %correct |
| Efficiency at half load | 94.3 %correct |
Origin and approval
| Country of manufacture | Brazilcorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2004correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the WEG KTE61 PHEM have?
The WEG KTE61 PHEM delivers 132 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
