WEG K23 EXNE2
Series: K23
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
WEG K23 – three-phase standard motor from the Brazilian maker in Jaraguá do Sul: MEPS register, 3 kW, four-pole, 415 V, IP55 protection, frame sizes 100 to 112
WEG was founded in 1961 in Jaraguá do Sul in the Brazilian state of Santa Catarina and is today one of the world's largest electric motor makers, with manufacturing in Brazil, Mexico, Portugal, China and India. This page gathers the five versions of the K23 range listed in the Australian MEPS register – ALE2, BRKLE2, EXDE2, EXNE2 and STDE2 – a small three-phase standard motor that WEG carries in its own catalogue as an IEC frame size.
Read on 3 more paragraphs
The register lists here five versions with 3 kW rated output, four-pole, for a 415 V supply. Full-load efficiency runs from 87.4 to 87.6%, and at 75% load from 86.6 to 87.4%. Protection is IP55 throughout, frame sizes run from 100 to 112, and manufacturing takes place in Brazil. Testing followed AS/NZS 1359.5:2004 with test method B; under the GEMS classification, none of the five versions reaches a High Efficiency Level. The mounting codes cover practically the whole spectrum, from the foot forms B3, B5, B14, B34 and B35 through B6, B7 and B8 to the flange and vertical forms V1, V3, V5, V6, V15, V18, V19 and V36.
Motors of this power class drive small pumps, fans, conveyor belts and compressors in industry and trade; in this lower power segment WEG competes with ABB, Siemens and Toshiba for applications where ruggedness and availability count more than efficiency class.
When buying used, what matters is bearing condition and a checked insulation resistance of the winding, visible corrosion or overheating marks on the terminal box and fan cover, the condition of shaft and key, and a legible nameplate with frame size, pole count and protection rating; anyone wanting to run the motor on a variable-speed drive should check its suitability beforehand. Spares run through the WEG distribution network.
Technical data
Engine
| Rated output | 3 kWcorrect |
|---|
Dimensions and weights
| Weight | 45 kgcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | 55correct |
| Frame size | 100 L (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B35, B34, B14, B6, B7, B8, V5, V6, V1, V3, V15, V36, V18, V19correct |
| Efficiency at full load | 87.6 %correct |
| Efficiency at 75 % load | 86.6 %correct |
| Efficiency at half load | 84.1 %correct |
Origin and approval
| Country of manufacture | Brazilcorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2004correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the WEG K23 EXNE2 have?
The WEG K23 EXNE2 delivers 3 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
