Volvo XC70

Built: 2003-2011 · Series: XC70

More machines from model year 2003

Wikimedia Commons · CC BY 4.0 · OWS Photography · Dateiseite

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Volvo XC70 is a machine built by Volvo. Production: 2003-2011. The engine delivers 120 kW, has 5 cylinders, with a displacement of 2,401 cm³. The machine is 4,840 mm long and 1,890 mm wide. The unladen weight is 1,839 kg. The wheelbase measures 2,820 mm. Top speed is 195 km/h. The gross vehicle weight is 2,400 kg. The machine runs on 4 wheels. Rated output across the Volvo range ranges from 11.2 to 552 kW; the XC70 sits in the lower part of that range with 120 kW. Its immediate neighbours are the 5D STW 940 94575/277 below it with 119.7 kW and the F85 above it with 121 kW. 5366 Volvo models across 29 series are on record. The model is listed under Vans. 13 verified figures from 1 source are on file.

Volvo XC70 – the collective page of the four-wheel-drive estate carried in the register as a light commercial vehicle (N1): five-cylinder D5 turbodiesel of 2,400 cm³ and 120 kW, lengths of around 4.73 to 4.84 m

This page gathers the Volvo XC70, the four-wheel-drive estate from the Swedish maker, carried in the register as a light commercial vehicle. The vehicles recorded here are based on the 2.4-litre five-cylinder D5 turbodiesel with automatic transmission and permanent four-wheel drive; the model names with suffixes such as STW for station wagon and internal type codes such as SZ7967 or SZ7994 follow the vehicle register's own system.

Read on 3 more paragraphs

The register lists here 7 versions with 120 kW from five-cylinders of 2,400 to 2,401 cm³, unladen weights from 1,763 to 1,846 kg, gross weights from 2,220 to 2,400 kg, lengths from 4,730 to 4,840 mm and widths from 1,860 to 1,890 mm.

The XC70 was designed as a passenger car, but because of its payload and estate body it was in some countries also registered as a light N1 commercial vehicle, for instance once the rear seat bench was removed and a continuous load floor created – a practice common in the Netherlands, which was more favourable for tax than regular passenger-car registration. Technically the XC70 remains a full-fledged four-wheel-drive estate combining car-like comfort with off-road ability.

On a used example of such an estate lightly re-registered as a commercial vehicle, the condition of the D5 turbodiesel and its charge-air ducting, the condition of the four-wheel-drive system and rear differential, corrosion at the strut mounts and, where the load floor has been converted, the proper execution of the panelling and lashing points all matter. Spare parts run through the regular Volvo network.

Sources: Kennwerte der Modelle Volvo XC70, Volvo Car Corporation (Hersteller), RDW (Niederlande)

Technical data

Engine

Power120 kWcorrect
Cylinders5correct
Displacement2,401 cm³correct

Dimensions and weights

Length4,840 mmcorrect
Width1,890 mmcorrect
Wheelbase2,820 mmcorrect
Unladen weight1,839 kgcorrect
Gross vehicle weight2,400 kgcorrect

Drivetrain and chassis

Wheels4correct
Top speed195 km/hcorrect

Where this model stands

Power-to-weight ratio: 65.3 kW/t (120 kW / 1.8 t)

Stronger than 81% of the vans in the register — out of 7,145 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Volvo XC70 have?

The Volvo XC70 delivers 120 kW.

How much does the Volvo XC70 weigh?

The unladen weight is 1,839 kg.

What is the gross vehicle weight of the Volvo XC70?

2,400 kg.

What engine does the Volvo XC70 have?

5 cylinders, 2,401 cm³ displacement.

What are the dimensions of the Volvo XC70?

4,840 mm × 1,890 mm.

When was the Volvo XC70 built?

Production years: 2003-2011.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 13 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
